SUPPLIED PARTS AND HARDWARE
NOTE: Not all hardware included in this kit will be used.
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged,
DO NOT return the damaged item to your dealer; contact Sanus (see back page). Never use damaged parts!
(qty. 1)
(qty. 4) each
1
Vertical Assembly
2
Extension Arm
Mount
Spacer
(qty. 2)
3
Soundbar Mount
TV Screws
M6/M8
Washer
(qty. 1)
4
M5 x 8 mm Screw
(qty. 4)
7
10
9
(qty. 4)
(qty. 2)
M5 x 14 mm Screw
5
(qty. 2)
22mm
Spacer
8
(qty. 4)
M3 Ball
Hex Key
(qty. 1)
5/64 Hex
Key
(qty. 1)
M5 x 25 mm Screw
6
(qty. 2)
11
12
