7
ATTACH SONOS
®
ARC
™
MOUNT TO TV INTERFACE MOUNT
3
5
3
9
10
6
≈ 1/4 in.
(6.35 mm)
CAUTION: Avoid potential
personal injury or property damage!
The brackets contain potential pinch points
during operation. Keep fingers away from
pinch points when retracting the brackets.
(see arrows)
IMPORTANT:
Partially insert the bolt leaving
a 1/8”-1/4” gap between the
bolt head and speaker.
6
12
11
11
6
11
6
11
11
12
IMPORTANT:
Tighten to a locked
position if desired.
Otherwise, keep tension
loose for free movement
To Next Page
