Sanus MF215 - Wall Mounting

6901-002090 <00>
14
2
Wall Mounting
For assistance in determining wall plate location, see Height Finder at sanus.com.
2-1: Wood Stud Mounting
CAUTION: Improper use could reduce the holding power of the lag bolt. To avoid potential injuries or property damage:
 Pilot holes MUST be drilled to a depth of 63.5 mm (2.5 in.), using a 5.5 mm (7/32 in.) diameter drill bit.
 Do not over-tighten the lag bolts [25].
 Any material covering the wall must not exceed 16 mm (5/8 in.).
2-2: Solid Concrete and Concrete Block Mounting
CAUTION: Improper use could reduce the holding power of the lag bolt. To avoid potential injuries or property damage:
 Pilot holes MUST be drilled to a depth of 75 mm (3 in.), using a 10 mm (3/8 in.) diameter drill bit.
 Be sure the anchors [27] seat  ush with the concrete surface.
 Mount wall plate directly onto the concrete surface.
 Never drill into the mortar between blocks.
 Do not over-tighten the lag bolts [25].
CAUTION:
