Sanus OLF22-B2 - Attach Wall Plate (Wood Studs)

12
1
2
MIN.
16 in.
(406 mm)
STEP 2A Attach Wall Plate Wood Stud Installation
MAX 5/8 in. (16 mm)
CAUTION: Avoid potential personal injury or property damage!
● Drywall covering the wall must not exceed 5/8 in. (16 mm)
● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1 ½ x 3 ½ in. (38 x 89 mm)
● Minimum horizontal space between fasteners: 16 in. (406 mm)
● Stud centers must be verified
07
