Sanus OLF22-B2 - Attach Wall Plate (Concrete)

14
CAUTION: Avoid potential personal injury or property damage!
● Mount the wall plate assembly
08
directly onto the concrete surface
● Minimum solid concrete thickness: 8 in. (203 mm)
● Minimum concrete block size: 8 x 8 x 16 in. (203 x 203 x 406 mm)
● Minimum horizontal space between fasteners: 16 in. (406 mm)
1
2
MIN.
16 in.
(406 mm)
002862.eps
STEP 2B Attach Wall Plate
Solid Concrete or Concrete Block Installation
07
07
3/8 in.
(10 mm)
3 in. (75 mm)
4X
