Sanus OLF22-B2 - Page 6

6
5/16 in.
5/16 x 2¾ in.
M5 x 8mm
M5
M6/M8
2.5mm
5mm
22mm
M8 x 50mm
M6 x 12mm
M6 x 35mmM6 x 20mm
M8 x 20mm
M8 x 40mm
M8x30 mm
Wall Plate Assembly
Wall Plate Template
Lag Screw
09
07
08
10
Washer [Lag Screw]
STEP 2 Parts and Hardware
qty. 1
qty. 4
qty. 4
qty. 1
Concrete Anchor
For concrete installations ONLY
CAUTION:
Do not use in drywall or wood
(qty. 4)
11
