4
24.0in
611mm
35deg 35deg
SIMULATED 90"
FLAT SCREEN TV
4deg
UP
15deg
DOWN
3.5in
88mm
3.2in
81mm
8.7in
220mm
17.3in
440mm
21.6in
550mm
28.5in
724mm
5deg
ROLL
25.8in
655mm
13.7in
347mm
11.6in
294mm
24.0in
610mm
16.0in
406mm
15.7in
400mm
23.6in
600mm
15.7in
400mm
7.9in
200mm
3.0in
75mm
3.9in
100mm
7.9in
200mm
3.0in
75mm
3.9in
100mm
TV INTERFACE
WALL PLATE TOP VIEW - EXTENDED
3-D
SIDE VIEW - EXTENDED
SIDE VIEW RETRACTED TOP VIEW - RETRACTED FULLY ASSEMBLED MOUNT
Dimensions
