CAUTION: Verify adequate
thread engagement with
your screw/washer/spacer
combination AND all brackets.
— Too short will not hold the TV.
— Too long will damage the TV.
Standard confi gurations shown.
For special applications, contact
Customer Service.
IMPORTANT:
To offset the shift in
height of your TV bracket, due to the
soundbar brackets
01
, you MUST use
washers
05
, in the top hole locations.
Side View
Step 3.1 Step 3.2
05 05
01 01
