Sanus SLF428-B2 - Supplied Parts and Hardware; TV Bracket Hardware (Step 1); Wall Plate Hardware (Step 2); Arm Assembly Hardware (Step 3)

4
1/4-20 x 1 in.
2.5mm
22mm
M6 x 20mmM6 x 12mm
M4 x 12mm
M6 x 35mm
M4 x 35mm
M5 x 11mm
5mm
10-32 x 3/8 in.
10-24 x 1/2 in.
M8 x 50mm
M8 x 16mm
M8 x 20mm
M8 x 30mm
M8 x 40mm
3/16 in.
5/16 x 3 ½ in.
Washers
(x 4 each)
03
02
01
M4
M4
M6/M8
M4/M6/M8
M6
M8
05
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do
not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
Supplied Parts and Hardware
TV Screws (x 4 each)
[Only one size fits your TV]
Spacers
(x 4 each)
[If necessary]
TV Bracket
Horizontal
TV Bracket
Vertical
M5 x 11MM
SCREW
06
(x 2)
04
STEP 3
STEP 1
1/4-20 x 1 in.
2.5mm
22mm
M6 x 20mmM6 x 12mm
M4 x 12mm
M6 x 35mm
M4 x 35mm
M5 x 11mm
5mm
10-32 x 3/8 in.
10-24 x 1/2 in.
M8 x 50mm
M8 x 16mm
M8 x 20mm
M8 x 30mm
M8 x 40mm
3/16 in.
5/16 x 3 ½ in.
Concrete Anchor
Arm Assembly
CAUTION: Do not use in drywall or wood.
1/4" x 1" Screw
#10 x 3/8" Screw
Hex Key
12 13 14
07
08
#10 x 1/2" Screw
Lag Screw
Drilling Template
Wall Plate
09
10
15
11
For concrete installations ONLY
(x 1)
(x 4)
(x 1)
(x 1)
(x 4)
(x 4)
(x 2) (x 2) (x 1)
(x 1)
(x 1)
STEP 2
NOTE: Not all hardware included will be used.
