Sanus SLF428-B2 - Step 3: Hang TV onto Wall Plate; Attach Arm Assembly to Wall Plate

8
11
11
08
08
08
11
3.1 Attach Arm Assembly to Wall Plate
STEP 3 Hang TV onto Wall Plate
HEAVY! You may need assistance with this step.
13
NOTE: For WOOD STUD APPLICATIONS, the arm
assembly
11
can be slid anywhere along wall plate
08
for
optimal positioning of your TV.
CAUTION: Avoid potential personal injury or property damage!
For CONCRETE APPLICATIONS:
The arm assembly
11
MUST remain centered in wall plate
08
.
1
3
2
4
11
08
