Sanus SLF5 - TV Adjustments; Rotate Adjustment; Tilt Adjustment

20
TV Adjustments
ROTATE ADJUSTMENT
Your TV should adjust easily when moved, then stay in place.
If your TV is too loose or too tight, adjust either the top tension knob
by hand or hex key
26
, or the top tension bolt using hex key
26
.
NOTE: Once your TV is in place, tighten the tension knobs to
prevent unwanted movement.
TILT ADJUSTMENT
Your TV should adjust easily when moved, then stay in place.
If your TV is too loose or too tight, adjust the side tension knob
by hand or use hex key
25
.
NOTE: Once your TV is in place, tighten the tension
knob to prevent unwanted movement.
25
Side Tension Knob
Tighten
Loosen
Top Tension
Bolt
26
Tighten
Loosen
26
Loosen
Top Tension
Knob
Tighten
