15
3 4
3. Remove the wall plate template
19
and insert six concrete anchors
23
(two on the bottom, four on top).
CAUTION: Be sure the anchors are seated flush with the concrete surface.
4. Install the wall plate
20
using six lag bolts
21
and six washers
22
(two on the bottom, four on top). Tighten all lag bolts only until they
are pulled firmly against the wall plate.
CAUTION: Avoid potential personal injury or property damage! All six lag bolts
21
MUST BE firmly tightened to prevent unwanted
movement of the wall plate
20
. Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
20
21
22
Solid Concrete or Concrete Block Installation
UP ARROW
23
