Sanus VLF320 - Adjustments; Level Adjustment Procedure; Tilt Tension Adjustment

18
Adjustments
TILTLEVEL
Your TV should adjust easily when moved, then stay in place.
Adjust the tilt tension knob
K
if your TV naturally tilts up or down.
NOTE: If you do not intend to adjust the tilt for different viewing locations,
you can tighten the tilt tension knob
K
to prevent unwanted movement.
Loosen the level screw
L
using hex key
26
,
adjust your TV, then tighten the level screw
L
.
K
L
19
26
19
25
