8
3. Position the TV bracket assembly over your TV hole pattern, center horizontally and
loosely install using the spacer, TV screw and washer combination (a) or (b) you
selected for your TV.
CAUTION: Avoid potential personal injury or property damage! The TV Bracket
assembly MUST BE installed with the release cord
R
oriented on the bottom of the
TV as shown.
If your TV included inset spacers or
wall mount adapters,
see Troubleshooting
on PAGES 26-27.
b
Spacer, screw and washer
a
Spacer, screw and washer
12
12
01
04
02
3
10
10
11
11
05
05
06
06
07
07
08
08
09
09
R
To Next Page
