7
IMPORTANT: For
ease of access, straps
should be level with
the bottom of the TV.
1-3 Attach TV Brackets
Center the TV brackets
01
and
02
over your TV hole pattern as shown - making sure the brackets are level.
NOTE: The tilt tension knob
T
on TV brackets
01
and
02
should be oriented to the outside edges.
Install using the spacer, screw and washer combination you selected for your TV.
a
Spacer, screw and washer
b
Spacer, screw and washer
10
10
08
08
09
09
03
03
04
04
05
05
06
06
07
07
0201
If your TV included inset spacers or wall mount adapters,
see Troubleshooting on PAGES 22-23.
T
Standard configurations are shown.
For special applications, or if you
are uncertain about your hardware
selection, contact Customer Service
at
1-800-359-5520
.
T
To Next Page
