15
All four lag bolts
17
MUST BE firmly tightened to prevent
unwanted movement of the wall plate
16
.
Ensure the wall plate is
securely fastened to the wall before continuing on to the next step.
CAUTION:
Avoid potential personal injury or property damage!
16
4X
17
14
18
4X
CAUTION:
Be sure the anchors
18
are seated fl ush
with the concrete surface.
CAUTION:
5
SECURELY TIGHTEN
Install four lag bolts
17
. Firmly tighten all four lag bolts
17
until they
are pulled flush against the wall plate
16
.
Insert four anchors
18
.
34
INSERT ANCHORS
Go to STEP 3 on PAGE 19Go to STEP 3 on PAGE 19
