Sanus VML41 - Adjustments and Specifications; Adjustments; Dimensions

13
Adjustments
LevelLateral Shift Remove the TV
Slide the TV side to side.
Make sure your TV is locked to wall
plate
17
(STEP 3-3).
Remove the TV.
Loosen both screws
21
, adjust the
level, then retighten the screws
(STEP 2-3A or 2-2B).
Disconnect your cables.
Unlock wall plate
17
(STEP 1-3).
Lift the TV up and away.
Loosen
Loosen
Tighten
Tighten
Dimensions ( in. [mm] )
0.20
5.1
1.12
28.6
1.10
27.9
0.98
25.0
5°
OPTIONAL
TILT
1.5°
LEVELING
1.5°
0.34
8.8
2.77
70.3
17.75
450.9
2.95
75.0
15.91
404.0
16.00
406.4
3.40
86.4
LATERAL SHIFT
21
21
17
17
