Sanus VML5 - STEP 2 C Solid Concrete or Concrete Block Option

14
CAUTION: Avoid potential personal injuries and property damage! Mount the wall plate
10
directly onto the concrete surface.
09
09
STEP 2C Solid Concrete or Concrete Block Option
Min.
406 mm
(16 in.)
Min.
203 mm
(8 in.)
Min.
406 mm
(16 in.)
Min.
203 mm
(8 in.)
Min.
203 mm
(8 in.)
002862.eps
2
1
10 mm
(3/8 in.)
10 mm
75 mm (3 in.)
