10
1-5 Attach TV Bracket 200 x 100 mm and 100 x 100 mm
Position the TV bracket
01
over your TV hole pattern and install using the screw, washer, and spacer (if needed) combination you selected for
your TV.
M4/M6/M8 spacer, screw, and washer
M4/M6/M8 screw and washer
01
7.87
200.0
3.94
100.0
3.94
100.0
05
15
15
07
16
16
08 10
11
13 14
06
09 12
To Next Page
