1-5 Attach TV Bracket with 200 x 200 mm Extensions
Position the TV bracket
01
with extensions
02
over your TV hole pattern and install using the screw, washer, and spacer (if needed)
combination you selected for your TV.
M6/M8 spacer, screw, and washer
M4/M6/M8 screw and washer
M4 spacer, screw, and washers
061513 15
05
15
07
16
08 10
11
16
14
09 12
01
02
