Service Manual MS CE25FN1-E
18
21. CE25FN1-E CABINET PARTS LIST
Location Part No. Description
YP 4 0020125209 SANYO Badge 46,2X13,5 L46
YP 5 0340207000 TRANS. DEC BOARD F3SCM
YF 1 2700046713 Front Cabinet Assy 25" A F3PC
YF 2 0590264719 Back Cover 25" A-F3PAM
YF 3 0130214000 Power BUTTON F3SCM
YF 4 0010106607 Key Spring
YF 6 0390242105 Rating Plate CE25FN1-E
YF 8-1 0590264867 DOOR 25/28 F3SC EB-5A
YF 9 0020128708 DEC SHEET 21/25/28 EB-5A
YF14 0200819910 AC Cord Holder
YF15 0050708718 Washer
YF18 0010108231 Cover CLIP
YF23 0890161326 Screw HI-LO 5,8X27 W/Washer
YF24 0890191315 Screw AR 4X15
YF25 0890190903 Screw 4X13
YF30 0970136008 Adhesive Tape PS
