Service Manual MS CE25FN1-E
Location Part No. Description Location Part No. Description
20
23. Parts List
PCB SOCKET TRC
CONNECTORS
CON FD 0330144205 Ribbon Wire Holder 4 P.
CON FH 0330144304 Ribbon Wire Holder 5 P.
CON.FD 0160220711 Polarised Band Grey 4P. 520+6+6
CON.FH 0160230819 Polarised Band Grey 5P. 450+6+6
CON.FK 0640202610 Earth Wire 270 mm.
CAPACITORS
C500 0270341324 Polyester 100 nF. 10% 250V.
C501 0250322849 Electrolytic 10 µF. 250V.
C503 0240590901 Ceramic 2200pF +80-20% 2KV.
DIODES
D500 0360007215 BAV21 DIODE
D501 0360007215 BAV21 DIODE
D502 0360007215 BAV21 DIODE
INTEGRATED CIRCUIT
IC500 0360514202 TDA 6107 Q N1
COILS
L503 0790701106 SMD 0 Ω 1/10W.
L504 0790701106 SMD 0 Ω 1/10W.
L505 0090304924 Choke R.F. 470 µH. 10%
PCB04 0750151029 Socket PCB EB5-A
RESISTORS
R500 0790741409 Solid 1,5 KΩ 10% 1/2W.
R501 0790741409 Solid 1,5 KΩ 10% 1/2W.
R502 0790741409 Solid 1,5 KΩ 10% 1/2W.
R503 0790741409 Solid 1,5 KΩ 10% 1/2W.
R504 0790741409 Solid 1,5 KΩ 10% 1/2W.
R506 25”/28” 0790539704 Fuse 22 Ω 5% 0,3W.
R506 21” 0790535702 Fuse 10 Ω 5% 0,33W.
R507 0790227003 R.M.G. 100 Ω 5% 1/10W
R508 0790227003 R.M.G. 100 Ω 5% 1/10W
R509 0790227003 R.M.G. 100 Ω 5% 1/10W
R510 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
R511 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
R512 0790242002 R.M.G. SMD 1,8 KΩ 5% 1/10W.
ZOCALO 0330162009 CRT Socket DIAMETER 22,5 mm.
MAIN PCB
CF200 0090412701 Ceramic TRAP Filter 5,5/6,5 MHz
CONNECTORS
CN FB 0330193608 4P. Connector
CN FC 0330115106 2P. Socket X RTM 1/6/8
CN FD 0330144205 Ribbon Wire Holder 4 P.
CN FE 0330115106 2P. Socket X RTM 1/6/8
CN FF1 0330190000 2P. Connector
CN FF2 0330270109 2 P. Socket
CN FH 0330144304 Ribbon Wire Holder 5 P.
CN G2 25”/28” 0640706503 Blue G2 Wire with two Terminals
CAPACITORS
C100 0230600504 Ceramic SMD 100 nF. 10% 25V.
C101 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C102 0230600504 Ceramic SMD 100 nF. 10% 25V.
C103 0250320769 Electrolytic 10 µF. 16V.
C104 0230600504 Ceramic SMD 100 nF. 10% 25V.
C105 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1050 25”/28” 0230600504 Ceramic SMD 100 nF. 10% 25V.
C1051 25”/28” 0250320769 Electrolytic 10 µF. 16V.
C1052 25”/28” 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1053 25”/28” 0230600504 Ceramic SMD 100 nF. 10% 25V.
C1054 25”/28” 0230600504 Ceramic SMD 100 nF. 10% 25V.
C1055 25”/28” 0230600504 Ceramic SMD 100 nF. 10% 25V.
C1056 25”/28” 0250320769 Electrolytic 10 µF. 16V.
C1057 25”/28” 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1058 25”/28” 0250461266 Electrolytic 100 µF. 16V.
C1059 25”/28” 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C106 0270101231 Polyester 1000pF. 5% 63V.
C1060 25”/28” 0250320769 Electrolytic 10 µF. 16V.
C1061 25”/28” 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1062 X25”/28” 0230190308 Ceramic SMD 39 pF. 5% 50V.
C1063 X25”/28” 0230190308 Ceramic SMD 39 pF. 5% 50V.
C107 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C108 0230160327 Ceramic SMD 22 pF. 1% 50V.
C109 0230160327 Ceramic SMD 22 pF. 1% 50V.
C110 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C111 0250320769 Electrolytic 10 µF. 16V.
C112 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C113 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C114 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C115 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C116 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C117 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C118 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C1351 0250320769 Electrolytic 10 µF. 16V.
C1352 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C1353 0250280864 Electrolytic 4,7 µF. 25V.
C1354 0250280864 Electrolytic 4,7 µF. 25V.
C1355 0230680308 Ceramic SMD 470 nF. 10% 16V.
C1356 0230190704 Ceramic SMD. 8 pF. +/-0,5pF. 50V.
C1358 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C1359 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C200 0250320769 Electrolytic 10 µF. 16V.
C201 0230190308 Ceramic SMD 39 pF. 5% 50V.
C202 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C203 0230600504 Ceramic SMD 100 nF. 10% 25V.
C204 0230600504 Ceramic SMD 100 nF. 10% 25V.
C205 0230740003 Ceramic SMD 2,2 µF. 10V. +80-20%
C206 X 0230190308 Ceramic SMD 39 pF. 5% 50V.
C207 0250320769 Electrolytic 10 µF. 16V.
C250 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C251 0250461266 Electrolytic 100 µF. 16V.
C252 0270341480 Polyester 100 nF. 10% 63V.
C256 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C257 0270341480 Polyester 100 nF. 10% 63V.
C258 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C259 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C260 0250360468 Electrolytic 22 µF. 16V.
C261 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C300 0250601069 Electrolytic 2200 µF. 35V. R-7,5
C301 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C303 0250410867 Electrolytic 47 µF. 16V.
C304 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C305 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C306 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C307 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C308 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C309 0250240462 Electrolytic 2,2 µF. 63V.
C310 0250240462 Electrolytic 2,2 µF. 63V.
C311 0250601663 Electrolytic 2200 µF. 16V.
C312 0250601663 Electrolytic 2200 µF. 16V.
C313 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C314 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C315 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C316 X 0230320301 Ceramic SMD 470 pF. 10% 50V.
C319 0250360468 Electrolytic 22 µF. 16V.
C320 0250360468 Electrolytic 22 µF. 16V.
C350 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C351 X 0230360406 Ceramic SMD 1000 pF. 10% 50V.
C352 0250410867 Electrolytic 47 µF. 16V.
C353 0250410867 Electrolytic 47 µF. 16V.
C354 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C355 0230600603 Ceramic SMD 100 nF. +80-20% 25V.
C356 0250500667 Electrolytic 220 µF. 16V.
C357 0250461266 Electrolytic 100 µF. 16V.
C359 0230480600 Ceramic SMD 10 nF. +80-20% 50V
C361 0250461266 Electrolytic 100 µF. 16V.
