2-2. Major Component Specifications
2-2-1. Indoor Unit
Indoor unit KHS1232
Remote Control Unit RCS-KHS2422W
POW-KHS1222-A
Control circuit fuse AC 250V - 3A
Switch Ass’y SW-KHS2412W
AH-KH1212
Input (230 / 208V) kW 1.5 / 1.23
Protective thermostat OFF 140 ± 5°F, ON 122 ± 9°F
Thermo fuse Cut-off 341 + 2, –5°F, 277V - 15A
Type Cross-flow
Number … Dia. and length in. (mm) 1 … O.D. 4 (100), L 30 (760)
Model … Number UF4Q-11A6P … 1
No. of pole … rpm (230V, High) 4 … 1,330
Nominal output W 10
Coil resistance Ω BRN – WHT: 281.6
(Ambient temp. 68°F)
WHT – VLT: 45.3
VLT – ORG: 56.0
ORG – YEL: 117.0
YEL – PNK: 59.4
Safety
Type Internal protector
Operating
Open °F 248 ± 9
devices
temp.
Close Automatic reclosing
Run capacitor
µF 0.8
VAC 440
Model M2EA24ZA01
Rating 208 to 230V, 60Hz
No. of pole … rpm 8 … 3
Output W 2.5
Coil resistance (at 68°F) kΩ 16.45 ± 15%
Coil Aluminum plate fin / Copper tube
Rows … Fins per inch 2 … 14.1
Face area ft.
2
(m
2
) 2.08 (0.19)
Controller
PCB
Fan
Heater Element
(Aux. Heater)
Fan Motor
Heat
Exch.
Louver
Motor
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
