POW-CH1232
Control circuit fuse AC 250V - 3A
Type Rotary (hermetic)
Model … Number C-R95H6E … 1
No. of cyl. … rpm 1 … 3,500
Nominal output W 950
Compressor lubricant cc 600
Coil resistance Ω C – R: 1.89
(Ambient temp. 77°F) C – S: 4.90
Type Internal External
Overload relay models — MST00AKU-9200
Safety
Operating
Open °F — 275 ± 9
devices
temp.
Close °F — 156 ± 27
Operating amp.
—
Trip in 6 to 16 sec.
(Ambient temp. 77°F) at 21.0A
Run capacitor
µF 20
VAC 400
Crank case heater 230V - 20W
Type Propeller
Number … Dia. in. (mm) 1 … 15-3/4 (400)
Model UE6S-21L6P
No. of pole … rpm (230V, High) 6 … 840
Nominal output W 20
Coil resistance
Ω BRN – WHT: 201.7
WHT – YEL: 156.1
(Ambient temp. 68°F)
YEL – PNK: 27.1
Safety
Type Internal protector
Operating
Open °F 248 ± 9
devices
temp.
Close Automatic reclosing
Run capacitor
µF 2.5
VAC 440
Coil Aluminum plate fin / Copper tube
Rows … Fins per inch 2 … 15.9
Face area ft.
2
(m
2
) 3.29 (0.30)
External Finish Acrylic baked-on enamel finish
4
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Compressor
Fan Motor
Fan
Heat
Exch.
Controller
PCB
2-2-2. Outdoor Unit
Outdoor unit CH1232
