- 10 -
PARTS LIST
TUNER & AMPLIFIER P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 315 1289 ASSY,PWB TUNER & AMPLIFIER
(Only Initial)
C2102 404 079 6305 ELECT 10U M 50V
C2306 404 079 6008 ELECT 1U M 50V
C2307 404 079 6305 ELECT 10U M 50V
C2311 404 079 6305 ELECT 10U M 50V
C2313 404 079 6008 ELECT 1U M 50V
C2321 404 079 6008 ELECT 1U M 50V
C2327 404 079 6305 ELECT 10U M 50V
C2328 404 079 6305 ELECT 10U M 50V
C2451 404 079 6305 ELECT 10U M 50V
C2457 403 259 0508 NP-ELECT 1U M 50V
C2503 404 079 6305 ELECT 10U M 50V
C4505 404 079 6008 ELECT 1U M 50V
C4555 404 079 6107 ELECT 47U M 16V
C4556 404 079 6305 ELECT 10U M 50V
C4560 404 079 6305 ELECT 10U M 50V
C4600 404 079 6008 ELECT 1U M 50V
C4601 403 057 3503 POLYESTER 0.1U K 50V
C4602 404 079 6305 ELECT 10U M 50V
C4603 404 079 6305 ELECT 10U M 50V
C4605 403 061 3605 POLYESTER 0.039U J 50V
C4606 403 061 7702 POLYESTER 4700P J 50V
C4607 403 059 3204 POLYESTER 2200P J 50V
C4608 403 060 2807 POLYESTER 0.027U K 50V
C4609 404 079 6107 ELECT 47U M 16V
C4702 404 079 6008 ELECT 1U M 50V
C4704 404 079 6008 ELECT 1U M 50V
C4707 404 079 6008 ELECT 1U M 50V
C4720 404 079 6008 ELECT 1U M 50V
C4721 404 079 6008 ELECT 1U M 50V
C4722 404 079 6008 ELECT 1U M 50V
C4723 404 079 6008 ELECT 1U M 50V
C4724 404 079 6008 ELECT 1U M 50V
C4725 404 079 6008 ELECT 1U M 50V
C4731 404 079 6008 ELECT 1U M 50V
C4732 404 079 6305 ELECT 10U M 50V
C4733 404 079 6008 ELECT 1U M 50V
C4734 404 079 6008 ELECT 1U M 50V
C4742 403 277 4106 ELECT 1000U M 25V
C4743 403 057 3503 POLYESTER 0.1U K 50V
C4802 404 079 6008 ELECT 1U M 50V
C4804 404 079 6008 ELECT 1U M 50V
C4807 404 079 6008 ELECT 1U M 50V
C4820 404 079 6008 ELECT 1U M 50V
C4821 404 079 6008 ELECT 1U M 50V
C4822 404 079 6008 ELECT 1U M 50V
C4823 404 079 6008 ELECT 1U M 50V
C4824 404 079 6008 ELECT 1U M 50V
C4825 404 079 6008 ELECT 1U M 50V
C4831 404 079 6008 ELECT 1U M 50V
C4832 404 079 6305 ELECT 10U M 50V
C4833 404 079 6008 ELECT 1U M 50V
C4834 404 079 6008 ELECT 1U M 50V
C4842 403 277 4106 ELECT 1000U M 25V
C4843 403 057 3503 POLYESTER 0.1U K 50V
C4924 404 079 6206 ELECT 10U M 25V
C4932 404 079 6008 ELECT 1U M 50V
C4950 403 332 7400 ELECT 2200U M 50V
C4984 403 194 3800 ELECT 2200U M 25V
or 403 329 3309 ELECT 2200U M 25V
CN201 614 255 5750 TERMINAL
or 645 032 6394 TERMINAL
CN400 645 012 5362 SOCKET,FPC 32P
CN430 645 005 7373 PLUG,3P
or 614 310 2441 PLUG,3P
CN431 407 218 1100 PHOTO COUPLE GP1FA550TZ
REF.NO. PART NO. DESCRIPTION
or 407 215 1608 PHOTO COUPLE TOTX178A
CN440 614 310 2472 PLUG,6P
or 645 005 8127 PLUG,6P
CN441 614 310 2748 PLUG,3P,POWER
or 645 004 2898 PLUG,3P,POWER
CN445 614 310 2519 PLUG,10P
or 645 005 8158 PLUG,10P
CN450 614 276 6835 SOCKET,JACK
CN455 645 011 6384 JACK,PHONE D3.6,HEADPHONE
CN456 645 006 1875 PLUG,2P,SPEAKER
CN457 645 006 1875 PLUG,2P,SPEAKER
CN458 645 043 8905 JACK,RCA
CT251 645 032 5236 TRIMMER,18PF
CT252 645 032 5663 TRIMMER,7PF
D2103 407 012 4406 DIODE 1SS133
D2104 407 012 4406 DIODE 1SS133
D2151 407 012 4406 DIODE 1SS133
D2153 407 105 1305 VARACTOR DI SVC342L-V
or 407 105 1602 VARACTOR DI SVC342M-V
D2301 407 063 9108 ZENER DIODE MTZJ6.8B
D2450 407 012 4406 DIODE 1SS133
D2451 407 012 4406 DIODE 1SS133
D2452 407 153 7502 ZENER DIODE GZS3.0B
D2453 407 012 4406 DIODE 1SS133
D2454 407 012 4406 DIODE 1SS133
D2455 407 012 4406 DIODE 1SS133
D2456 407 012 4406 DIODE 1SS133
D2466 407 012 4406 DIODE 1SS133
D2467 407 012 4406 DIODE 1SS133
D4500 407 012 4406 DIODE 1SS133
D4960 407 012 4406 DIODE 1SS133
D4991 407 099 6805 ZENER DIODE MTZJ13B
D4992
!
!!
407 099 6003 ZENER DIODE MTZJ9.1B
D4993 407 012 4406 DIODE 1SS133
HS401 614 314 3017 HEAT SINK,HEATSINK
IC231 409 474 3201 IC LA1844ML
IC241 409 439 4502 IC LC72121M-D
IC251 409 447 3900 IC LC72722
IC440 409 451 7406 IC AN7348K
IC441 409 500 2208 IC LC75343-MPB
IC442
!
!!
409 451 2104 IC TDA7269
IC443 409 189 3404 IC BA7755A
IC445 409 469 6200 IC MM1453XF
IC446
!
!!
409 039 9204 IC NJM78L05A
L2100
!
!!
645 037 2858 CORE,PIPE
L2101
!
!!
645 037 2858 CORE,PIPE
L2151 645 040 2685 TRANS,ANT,796KHZ
L2152 645 046 7998 TRANS,ANT,796KHZ
L2153 645 040 2708 TRANS,OSC,796KHZ
L2154 645 040 2722 TRANS,OSC,796KHZ
L2301 645 004 0580 INDUCTOR,1M J
L2451 645 031 7842 INDUCTOR,100U K
or 645 001 4581 INDUCTOR,100U K
L2501 645 031 7842 INDUCTOR,100U K
or 645 001 4581 INDUCTOR,100U K
L2502 645 031 7842 INDUCTOR,100U K
or 645 001 4581 INDUCTOR,100U K
L4600 645 006 1523 INDUCTOR,470U J
L4601 645 006 1523 INDUCTOR,470U J
L4602 645 037 2858 CORE,PIPE
L4603 645 006 1523 INDUCTOR,470U J
L4604 645 037 2858 CORE,PIPE
L4781 645 006 9864 INDUCTOR,80U
L4782 645 006 9864 INDUCTOR,80U
L4881 645 006 9864 INDUCTOR,80U
L4882 645 006 9864 INDUCTOR,80U
LUG45 614 129 9068 LUG
LUG46 614 129 9082 LUG
