- 8 -

PARTS LIST

CD P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

71 614 314 9606 ASSY,PWB CD (Only Initial)

C1317 404 085 3909 ELECT 0.22U M 50V

C1330 404 079 6206 ELECT 10U M 25V

C1335 404 079 6206 ELECT 10U M 25V

C1338 404 079 6206 ELECT 10U M 25V

C1339 404 079 6206 ELECT 10U M 25V

C1773 404 079 6206 ELECT 10U M 25V

C1783 404 079 6206 ELECT 10U M 25V

CN111 645 026 2463 SOCKET,FFC 15P

or 645 040 0513 SOCKET,FPC 15P

CN113 645 005 8127 PLUG,6P,BASEMECHA

or 614 310 2472 PLUG,6P,BASEMECHA

CN114 645 005 9292 PLUG,5P

or 614 310 2465 PLUG,5P

CN115 614 316 7990 ASSY,WIRE,WIRE

D1211 407 099 4603 ZENER DIODE MTZJ3.9B

D1402 407 099 5204 ZENER DIODE MTZJ5.1B

D1404 407 012 4406 DIODE 1SS133

IC101 409 396 8100 IC LA9241ML

IC102 409 435 2106 IC LC78622NE

IC103

409 372 9602 IC LA6541

IC104

409 441 4507 IC TA7291S(M)

L1451 645 031 7835 INDUCTOR,10U K

or 645 001 4550 INDUCTOR,10U K

PR140

645 014 2499 PROTECTOR,0.4A 125V

Q1301 405 008 6809 TR 2SB808-F-SPA

or 405 151 4509 TR KTA1270-Y

or 405 151 4608 TR KTA1270-O

or 405 008 7103 TR 2SB808-G-SPA

Q1401

405 009 5306 TR 2SB927-T

405 009 5207 TR 2SB927-S

405 141 3604 TR KTA1273-Y

R1211

402 082 0709 RESISTOR 5.6 J- 2W

R1212 401 105 0504 MT-GLAZE 1K JA 1/16W

R1301 401 105 0504 MT-GLAZE 1K JA 1/16W

R1302 401 105 0306 MT-GLAZE 10 JA 1/16W

R1303 401 105 0702 MT-GLAZE 100K JA 1/16W

R1304 401 105 6605 MT-GLAZE 6.8K JA 1/16W

R1305 401 105 2805 MT-GLAZE 2.2K JA 1/16W

R1308 401 105 3406 MT-GLAZE 27K JA 1/16W

R1309 401 105 4007 MT-GLAZE 330 JA 1/16W

R1310 401 105 1600 MT-GLAZE 15K JA 1/16W

R1311 401 105 0702 MT-GLAZE 100K JA 1/16W

R1312 401 105 6605 MT-GLAZE 6.8K JA 1/16W

R1313 401 105 2904 MT-GLAZE 22K JA 1/16W

R1314 401 105 2904 MT-GLAZE 22K JA 1/16W

R1315 401 105 1600 MT-GLAZE 15K JA 1/16W

R1317 401 105 8203 MT-GLAZE 68K JA 1/16W

R1318 401 105 1501 MT-GLAZE 1.5K JA 1/16W

R1320 401 105 7404 MT-GLAZE 8.2K JA 1/16W

R1324 401 105 4205 MT-GLAZE 33K JA 1/16W

R1325 401 105 8104 MT-GLAZE 56K JA 1/16W

R1326 401 105 0504 MT-GLAZE 1K JA 1/16W

R1327 401 105 8104 MT-GLAZE 56K JA 1/16W

R1328 401 105 6605 MT-GLAZE 6.8K JA 1/16W

R1329 401 105 0603 MT-GLAZE 10K JA 1/16W

R1330 401 105 3000 MT-GLAZE 220K JA 1/16W

R1331 401 105 3000 MT-GLAZE 220K JA 1/16W

R1332 401 105 1600 MT-GLAZE 15K JA 1/16W

R1333 401 105 1105 MT-GLAZE 12K JA 1/16W

R1334 401 105 0504 MT-GLAZE 1K JA 1/16W

R1335 401 105 0603 MT-GLAZE 10K JA 1/16W

R1336 401 105 4007 MT-GLAZE 330 JA 1/16W

R1337 401 105 6605 MT-GLAZE 6.8K JA 1/16W

R1343 401 105 0702 MT-GLAZE 100K JA 1/16W

R1401 401 105 1402 MT-GLAZE 150 JA 1/16W

FRONT P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

72 614 314 9590 ASSY,PWB FRONT (Only Initial)

AH601 614 314 2621 HOLDER,LCD,HOLDER_LCD

AR601 614 315 6505 REFLECTOR,REFLECTOR_LCD

AS601 614 314 3000 DEC,SHEET,LCD,DEC_SHEET_LCD

C6010 403 350 7802 ELECT 1000U M 6.3V

or 403 325 0401 ELECT 1000U M 6.3V

or 403 196 4102 ELECT 1000U M 6.3V

C6011 403 262 8607 DL-ELECT 0.047F Z 5.5V

or 403 304 4802 DL-ELECT 0.047F Z 5.5V

CN601 645 012 5362 SOCKET,FPC 32P

D6010 407 012 4406 DIODE 1SS133

D6110 407 012 4406 DIODE 1SS133

D6111 407 012 4406 DIODE 1SS133

D6112 407 012 4406 DIODE 1SS133

D6113 407 012 4406 DIODE 1SS133

D6114 407 099 5303 ZENER DIODE MTZJ5.6B

D6115 407 099 4603 ZENER DIODE MTZJ3.9B

D6310 407 221 6109 LED FA5366X

D6311 407 221 6208 LED DB5306

IC601 410 405 4204 IC LC867240A-5V46

L6010 645 001 5441 INDUCTOR,2.2U K

LCD60 645 043 6239 LCD

Q6101 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

Q6102 405 004 5004 TR 2SA608-G-NP

or 405 004 4502 TR 2SA608-F-NP

or 405 141 3505 TR KTA1266-Y

or 405 141 3406 TR KTA1266-GR

Q6103 405 004 4502 TR 2SA608-F-NP

or 405 004 5004 TR 2SA608-G-NP

or 405 141 3505 TR KTA1266-Y

or 405 141 3406 TR KTA1266-GR

Q6105 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

REF.NO. PART NO. DESCRIPTION

R1453 401 105 3307 MT-GLAZE 2.7K JA 1/16W

R1454 401 105 6506 MT-GLAZE 680 JA 1/16W

R1455 401 105 8203 MT-GLAZE 68K JA 1/16W

R1456 401 105 1006 MT-GLAZE 1.2K JA 1/16W

R1458 401 105 5103 MT-GLAZE 47 JA 1/16W

R1462 401 105 5905 MT-GLAZE 560 JA 1/16W

R1463 401 105 5905 MT-GLAZE 560 JA 1/16W

R1464 401 105 0504 MT-GLAZE 1K JA 1/16W

R1465 401 105 5905 MT-GLAZE 560 JA 1/16W

R1470 401 105 0405 MT-GLAZE 100 JA 1/16W

R1472 401 105 5301 MT-GLAZE 4.7K JA 1/16W

R1473 401 105 0702 MT-GLAZE 100K JA 1/16W

R1475 401 105 5905 MT-GLAZE 560 JA 1/16W

R1480 401 105 5905 MT-GLAZE 560 JA 1/16W

R1490 401 105 6100 MT-GLAZE 560K JA 1/16W

R1498 401 105 0405 MT-GLAZE 100 JA 1/16W

R1499 401 105 0405 MT-GLAZE 100 JA 1/16W

R1501 401 105 1501 MT-GLAZE 1.5K JA 1/16W

R1502 401 105 4106 MT-GLAZE 3.3K JA 1/16W

R1503 401 105 1501 MT-GLAZE 1.5K JA 1/16W

R1771 401 105 0504 MT-GLAZE 1K JA 1/16W

R1773 401 105 0702 MT-GLAZE 100K JA 1/16W

R1781 401 105 0504 MT-GLAZE 1K JA 1/16W

R1783 401 105 0702 MT-GLAZE 100K JA 1/16W

X1451 645 020 9024 OSC,CRYSTAL 16.9344MHZ
