- 35 -
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PARTS LIST
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 302 5276 CARTON CASE,INNER SLEEVE
614 302 0752 CUSHION,FRONT
614 302 0769 CUSHION,BACK
614 231 6832 LABEL,SAFETY,CLASS 1
645 036 4334 POLY SHEET-0750X0400*NC,SET
(DC-X5C/UK,DC-X5CT/UK)
645 036 4341 POLY SHEET-0750X0400*NC,SET
(DC-077C/XE)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 309 7099 ASSY,CABINET,FRONT
2 614 309 7228 BUTTON,OPEN,OPEN/CLOSE
3 614 302 0622 REFLECTOR,DISC SELECT
4 614 302 0530 DEC,WINDOW LED,PLAY
5 614 309 7259 BUTTON,DISC SELECT
6 614 309 7235 BUTTON,PLAY,PLAY/PAUSE
7 614 309 6993 ASSY CABINET,AFTER BENDING
8 614 309 7402 DEC,ESCUTCHEON,DISC TRAY
9 614 130 0382 LUG,CD MECHA LEAD DRESS
10 614 309 7549 PANEL,REAR
(DC-X5C/UK,DC-X5CT/UK)
10 614 309 8089 PANEL,REAR
(DC-077C/XE)
11 614 129 9082 LUG,FOR CD-MECHA WIRE
12 614 302 4798 ASSY,CABINET,BOTTOM
13 614 302 0554 DEC,SHEET,DISC SELECT
14 614 250 6721 FOOT,W/DOU CD MECHA
614 274 8190 LABEL,SAFETY,LASER
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3503 SCR S-TPG BIN 3X10,
FRONT-BOTTOM FIX
Y02 411 021 3503 SCR S-TPG BIN 3X10,FRONT PWB FIX
Y03 411 092 2900 WASHER Z 3X10X1,MECHA
Y04 411 028 9201 SCR S-TPG PAN 3X4,MECHA
Y05 411 021 3701 SCR S-TPG BIN 3X10,CABINET
Y06 411 021 3503 SCR S-TPG BIN 3X10,LUG
Y07 411 021 3503 SCR S-TPG BIN 3X10,
LEAD DRESS PWB
Y08 411 021 3701 SCR S-TPG BIN 3X10,BOTTOM-REAR
Y09 411 021 3701 SCR S-TPG BIN 3X10,
REAR-ELECT PART
Y10 411 020 9902 SCR S-TPG BRZ+FLG 3X8,CD MECHA
Y11 411 021 3503 SCR S-TPG BIN 3X10,SIDE PWB
Y12 411 008 0402 WASHER OUT TW 3,SIDE PWB
OPEN P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
71 614 302 4170 ASSY,PWB,OPEN (Only Initial)
CN164 614 035 4911 SOCKET,DIP 2P
or 614 237 9752 SOCKET
S1640 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
LED P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
72 614 302 4163 ASSY,PWB,LED (Only Initial)
CN162 614 035 4959 SOCKET,DIP 6P
CN163 614 035 4911 SOCKET,DIP 2P
or 614 237 9752 SOCKET
D1620 408 032 5404 LED SLP-9118C-51H-S-T1,
FORLED_RED
D1621 408 032 5404 LED SLP-9118C-51H-S-T1,
FORLED_RED
D1622 408 032 5404 LED SLP-9118C-51H-S-T1,
FORLED_RED
KEY P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 302 4156 ASSY,PWB,KEY (Only Initial)
CN160 645 006 0861 PLUG,7P
CN161 614 035 4959 SOCKET,DIP 6P
D1601 408 037 4204 LED SLP-3118B-51HAB-T1,
FOR_LED_YG
S1601 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S1602 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 305 2821 ASSY,WIRE,CD-FRONT(CN183)
or 614 308 5799 ASSY,WIRE,CD-FRONT(CN183)
52 645 037 0359 FLEXIBLE FLAT CABLE,
PICK UP(CN181)
53 614 305 2647 ASSY,WIRE,CD-MECHA(CN182)
or 614 308 5782 ASSY,WIRE,CD-MECHA(CN182)
54 614 305 2838 ASSY,WIRE,CD-DOUT(CN184)
or 614 308 5805 ASSY,WIRE,CD-DOUT(CN184)
55
!
!!
614 302 4644 PWB,FFC (N.S.P)
56
!
!!
614 304 7995 PWB,FFC2 (N.S.P)
