2-4: Confirmation of Fixed Value (Step No.)
Please check if the fixed values of each of the adjustment item is set correctly referring below.
(TV/AV/COMPONENT/HDMI/PC/DVD/DTV)
CVBS Y/C
480i 480p 720p 1080i 1080p VGA 480i 480p 720p 1080i 1080p VGA XGA 640x480 720x400 800x600 1024x768 1280x768 1280x720 1360x768 480i 480p 720p 1080i 1080p
Step No. Step No. Step No.
3 R DRIVE (N) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
4 R CUTOFF (N) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
5 G DRIVE (N) 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
6 G CUTOFF (N) 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
7 B DRIVE (N) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
8
B CUTOFF (N)
*
*
-
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Step No. Step No.
ELECTRICAL ADJUSTMENTS
PC/HDMI-DVI
DVD
PC DTV
NO. FUNCTION
Step No. Step No. Step No. Step No.
TV
AV
COMPONENT HDMI
D-4 D-5
8
B CUTOFF (N)
*
*
-
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
9 R DRIVE (C) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
10 R CUTOFF (C) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
11 G DRIVE (C) 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
12 G CUTOFF (C) 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
13 B DRIVE (C) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
14 B CUTOFF (C) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
15 R DRIVE (W) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
16 R CUTOFF (W) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
17 G DRIVE (W) 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
18 G CUTOFF (W) 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
19 B DRIVE (W) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
20 B CUTOFF (W) * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
29 BAK LIGHT CENT 54 54 - 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54 54
30 BAK LIGHT MAX 100 100 - 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
31 BAK LIGHT MIN 15 15 - 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
32 BRIGHT CENT 126 126 - 126 126 126 126 126 134 134 134 134 134 134 126 126 126 126 126 126 126 126 126 126 126 126 126 126 126
33 BRIGHT MAX 200 200 - 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
34 BRIGHT MIN 30 30 - 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
35
TINT
45
41
-
41
41
41
41
41
41
41
41
41
41
41
50
50
50
50
50
50
50
50
50
50
43
43
43
43
43
35 TINT 45 41 - 41 41 41 41 41 41 41 41 41 41 41 50 50 50 50 50 50 50 50 50 50 43 43 43 43 43
36 SHARP H1 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
37 SHARP H1 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
38 SHARP H2 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
39 SHARP H2 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
40 SHARP H3 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
41 SHARP H3 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
42 SHARP H4 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
43 SHARP H4 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
44 SHARP H5 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
45 SHARP H5 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
46 SHARP V1 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
47 SHARP V1 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
48 SHARP V2 MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
49 SHARP V2 MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
50 CONTRAST CENTER * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
51 CONTRAST MAX * * - * * * * * * * * * * * * * * * * * * * * * * * * * *
52 CONTRAST MIN 60 60 - 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
53
COLOR CENTER
183
215
-
200
200
200
200
200
200
200
200
200
200
200
183
183
200
183
183
183
183
183
183
183
200
200
200
200
200
53
COLOR CENTER
183
215
-
200
200
200
200
200
200
200
200
200
200
200
183
183
200
183
183
183
183
183
183
183
200
200
200
200
200
54 COLOR MAX 255 255 - 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255
55 COLOR MIN 0 0 - 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
58 CONTRAST 40 * * * * * * * * * * * * * * * * * * * * * * * * * * * *
-
NOTE:
For the step no. with * mark, please adjust it according to the situation of the set.
