Sanyo DP32671 - WAVEFORMS (CONTINUED); Additional Signal Waveforms

WAVEFORMS
MPEG/MICON/DSP VIDEO/AUDIO IN/OUT
5ns 50ms
200mV 1V
54 60
200ns
200mV
55
VIDEO/AUDIO IN/OUT
10us
200mV
56
56
10us
200mV
57
1ms
1V
58
1ms
1V
59
NOTE : The following waveforms were measured at
the point of the corresponding balloon
number in the schematic diagram.
H-2
