Sanyo DP55360 Service Manual

– 15 –
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
C6550 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6600 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6601 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6602 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6603 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6604 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6605 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6606 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6607 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6609 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6610 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6611 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6612 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6613 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6614 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6615 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6616 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6617 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6618 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6620 CK0J106KGMBNG CERAMIC 10U K 6.3V
C6621 CE1C101M1WANG ELECT 100U M 16V
C6624 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6625 CK1A105KLZBNG CERAMIC 1U K 10V
C6627 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C8500 CK1H103KLZBNG CERAMIC 0.01U K 50V
C8501 CK1A105KLZBNG CERAMIC 1U K 10V
C8503 CE1C221M1WANG ELECT 220U M 16V
C8504 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C8505 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C8550 CK1H103KLZBNG CERAMIC 0.01U K 50V
C8551 CK1A105KLZBNG CERAMIC 1U K 10V
C8553 CE1C221M1WANG ELECT 220U M 16V
DIODES
D007 DZ02DZ6.2Y—G ZENER DIODE 02DZ6.2Y(TPH3
DZUDZS6.2B—G ZD UDZS-TE-176.2B
DZXLBXB6.2B-G ZENER DIODE MM3Z6V2B
D008 DZ02DZ6.2Y—G ZENER DIODE 02DZ6.2Y(TPH3
DZUDZS6.2B—G ZD UDZS-TE-176.2B
DZXLBXB6.2B-G ZENER DIODE MM3Z6V2B
D800 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D801 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1001 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1002 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1602 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1603 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1604 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1605 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1632 DZ02DZ3.0Y—G ZENER DIODE 02DZ3.0Y(TPH3
DZUDZS3.0B—G ZENER DIODE UDZS3.0B-TE-1
DZXLBXB3.0B-G ZENER DIODE MM3Z3V0B
D1633 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1634 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1651 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1660 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1674 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1683 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1700 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D2402 DDRB551V-30-G DIODE RB551V-30-TE-17
D2403 DDRB551V-30-G DIODE RB551V-30-TE-17
SC8508 DDDF2S6.8UFSG DIODE DF2S6.8UFS
SC8509 DDDF2S6.8UFSG DIODE DF2S6.8UFS
SC8510 DDDF2S6.8UFSG DIODE DF2S6.8UFS
SC8511 DDDF2S6.8UFSG DIODE DF2S6.8UFS
INTEGRATED CIRCUITS
IC001 QSTA333W13TRP IC STA333W13TR
IC600 QLM1117S-ADJP IC LM1117S-ADJ
IC800 QXXAAJQ1240— IC LC87F2932AVU-Y10US1T
IC800A QXXGA0500125M IC LC87F2932AVU-QIP-E
IC801 QLE24C023M-EP IC LE24C023M-TLM-E
QXXAVC837—-P IC AT24C02BN-10SU-1.8
QXXAVC986—-P IC CAT24C02WI-GT3
IC804 QTC7SET14FU-P “IC TC7SET14FU-(TE85L,F”
QXXAVD177—-P “IC 74AHCT1G14GW,125”
IC1610 QBD9845FV—-P IC BD9845FV-E2
IC1611 QBD9845FV—-P IC BD9845FV-E2
IC1630 QPQ070XNA1ZPP IC PQ070XNA1ZPH
IC1640 QPQ070XNA1ZPP IC PQ070XNA1ZPH
IC1650 QLM1117S-ADJP IC LM1117S-ADJ
