ELECTRICAL PARTSLIST

LOC PARTS_CODE PARTS_NAME PARTS_DESCR REMARK

DW-PVMCASE541

CHASSIS MAIN AS DC-B89E1D-MS/H

A001 DW-97P0612710 CHASSIS MAIN HIPS(V0)

A002 DW-97P93617D0 LABEL SPEC PE FILM(131*47)

A003 DW-97P0992911 PLATE A/V BACK PVC T0.3

A005

DW-97P0482800

COVER BOTTOM SECC T0.8

A0051

DW-97P4220000

CUSHION LEG EVA T=2.0

A0052

DW-7174300811

SCREW TAPPTITE TT2 RND 3X8 MFZN

A040

DW-97P0483501

COVER TOP SECC T0.5+PAINT(HOLE 2 EA)

A040B

DW-97P4219700

CUSHION TOP PLATE EVA(SOFT) T=1 175*8

A041 DW-7173300812 SCREW TAPTITE TT2 BIN 3X8 BK

AJ01A DW-7173300812 SCREW TAPTITE TT2 BIN 3X8 BK

JACK A/V FIX

AP01A DW-7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN

AZ01A DW-7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN

BA03A

DW-97P0974800

PLATE EARTH TMI SUS304 CSP T0.2

D100 DW-97P1RA2CA0 REMOCON HANDSET AS VR-FA2CA0 GY3401A(AAA)

JA01A DW-7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN

M01

DW-97PP346010

PANEL FRONT AS DCSB89D1N-PS(V0)

M021 DW-7173401211 SCREW TAPPTITE TT2 BIN 4X12 MFZN DECK FIX

M022 DW-7174301211 SCREW TAPPTITE TT2 RND 3X12 MFZN DECK FIX

M023 DW-97PM000100 SCREW DECK AS PVC SWRCH1018A DECK FIX

M1000

DW-PVDKARPB66

DECK VCR AS(T50,F/L) DRP-B610R NON

M200 DW-PVLDASBD00 DVD MECHA AS COMBO,SANKYO (97Q6010200),V3.0

M200A DW-7174301211 SCREW TAPPTITE TT2 RND 3X12 MFZN

LOADER FIX

PD01A

DW-97P88FBF19

CABLE FFC 1.0 R 15P 190MM

PD02A

DW-97P88FBK20

CABLE FFC 1.0 R 19P 200MM

PW01

DW-97P69HB91B

CORD POWER SAA LP-15A(INSULATED PIN)

YFH800(TUBE) 1.7M

Z001

DW-PVMPMSE541

PCB MAIN MANUAL AS DC-B89E1D-MS/H

AM01

DW-2193100801

SOLDER WIRE SN:PB=63:37 3PI(NO FLUX)

AM02

DW-2193011100

SOLDER WIRE 60 SNA 1.2D

AM03

DW-2291050305

FLUX LIQUID RF-800KN

AM04

DW-2291050306

FLUX THINNER RF-800ADD

AM05

DW-2291140501

WAX COVER

AM06

DW-97P93B2101

LABEL CD(PCB) PAPER(13X25) ALL MODEL

E001 DW-97P0993100 PLATE EARTH C5210(PBS) T0.15(1/2H)

G701 DW-DEB83D1N LED DISPLAY EB83D1N-F425-2SRVYWB

H501

DW-10RC356VF4

IC UNIT R/RECE1VER ORC-356VF4(38KHZ)

IC502 DW-14CAT2416P IC EEPROM CAT24WC16P(16K DIP)

JK602 DW-97P6318210 JACK PIN DPAM-0274

JK603 DW-97P6318200 JACK PIN DPAM-0273

JK606 DW-97P0S03000 JACK SENSOR OPTIC VST5B-12M

JK701

DW-97P6316900

JACK PIN DPSE-9946

M401 DW-97P0478200 CASE SHI PREAMP ET T0.4

P201 DW-97P62Y1318 CONN WAFER DVW250 PLUG 2.5MM 8P

P202

DW-97P62T14B2

CONN HOUSING TMC-EX-B1 RECEP 2.0MM 2P

P401 DW-97P62G06DA CONN FFC GF120-10S-TS 10P ST

P501 DW-97P62J012C CONN B/B JE612 PLUG 2.0 12P

P604

DW-97P62M06A6

CONN B/B 35337 PLUG 2.5MM 6P

P701 DW-97P62A24B5 CONN WAFER 440055-5 RA PLUG 5P

P702 DW-97P62M05A6 CONN B/B 35238 RECEP 2.5MM 6P

P804 DW-97P62Y17AA CONN WAFER YW025-10 ST PLUG 2.5MM

PD01

DW-97P62G08EK

CONN FFC GF102-19S-TS 19P ST

PD02

DW-97P62G08EF

CONN FFC GF102-15S-TS 15P ST

PJ501 DW-97P885X226 CONN AS 5H-5S 150MM

PT01 DW-97P6269000 CONN WAFER 00-8283-0612-00000

RF101 DW-97P7621900 TUNER 3 IN 1 LG TMI-GKIQ5

LOC PARTS_CODE PARTS_NAME PARTS_DESCR REMARK

S501

DW-97P0S02700

SENSOR REEL KPI-261D

S502 DW-97P0S02700 SENSOR REEL KPI-261D

SW501 DW-5S10104200 SW MODE MMS01010ZMB0

SW601

DW-5SD0101100

SW DETE MXS00921MPC0

T201

DW-560202L692

COIL OSC DEO-006

X051

DW-5XJ18R4LAE

CRYSTAL QUARTZ HC-49/S 18.43200MHZ 30PP

X501 DW-5XJ17R7LAD CRYSTAL QUARTZ HC-49/S 17.73447MHZ 25PPM

Z0011 DW-PVMPJ1E541 MAIN CHIP MOUNT BT AS DC-B89E1D-MS/H

C008 DW-HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608

C009 DW-HCQK300JBA C CHIP CERA 50V CH 30PF J 1608

C012 DW-HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608

C015 DW-HCQK331JBA C CHIP CERA 50V CH 330PF J 1608

C017 DW-HCBK822KBA C CHIP CERA 50V X7R 8200PF K 1608

C018 DW-HCBK822KBA C CHIP CERA 50V X7R 8200PF K 1608

C028 DW-HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608

C051 DW-HCQK390JBA C CHIP CERA 50V CH 39PF J 1608

C052 DW-HCQK209CBA C CHIP CERA 50V CH 2PF C 1608

C053 DW-HCQK209CBA C CHIP CERA 50V CH 2PF C 1608

C054

DW-HCBK103KBA

C CHIP CERA 50V X7R 0.01MF K 1608

C056

DW-HCFH104ZBA

C CHIP CERA 25V Y5V 0.1MF Z 1608

C058

DW-HCFH104ZBA

C CHIP CERA 25V Y5V 0.1MF Z 1608

C060

DW-HCFH104ZBA

C CHIP CERA 25V Y5V 0.1MF Z 1608

C062 DW-HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608

C067 DW-HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608

C202 DW-HCBK152KBA C CHIP CERA 50V X7R 1500PF K 1608

C203

DW-HCBK122KBA

C CHIP CERA 50V X7R 1200PF K 1608

C206

DW-HCBK103KBA

C CHIP CERA 50V X7R 0.01MF K 1608

C212

DW-HCBK103KBA

C CHIP CERA 50V X7R 0.01MF K 1608

C218

DW-HCBK103KBA

C CHIP CERA 50V X7R 0.01MF K 1608

C220

DW-HCBK333KBA

C CHIP CERA 50V X7R 0.033MF K 1608

C251

DW-HCFH474ZBA
