2. Troubleshooting guide
2.1. No raster
Turn-on power supply, check
if the red indicator is light in
the STANDBY?
Check if PIN11(5V) of X401
on main board is normal?
Check STANDBY circuit of
power supply board
Press POWER button on the
unit or sensor control and
check the indicator.
Check if the PIN13 of X401
on main board is high-level?
Check if the PIN1 of X401 on
main board is low-level?
Check back light board
yes
no
Check the backlight
control circuit
blue
red
yes
no
no
yes
Check power
supply board
28
To Next Page
