Type: Integrated Digital LCD TV
Panel: 24” TFT LCD
Analogue TV system: PAL-B/G (CCIR), NTSC(AV)
Power Requirement: AC 220-240 V, 50/60 Hz
Power Consumption: 50 W
Dimensions (W x H x D):
574 (W) x 428 (H) x 188 (D)mm (stand included)
Weight: 5 kg (stand included)
Terminals:
Specifications
1. Design and specifications are subject to change without notice.
2. Weight and dimensions shown are approximate.
3. Specifications and external appearance may be changed for the sake of improvement.
Note:
Antenna in (1)
AV in (2)
COMPONENT in (1)
PC in (1)
HDMI in (2)
RS-232 (1)
Headphone (1)
USB port (1)
MUSIC port (1)
AV out (1)
S/PDIF coaxial out (1)
36
Digital TV system:
Compliant Standard: DVB-T, 7 MHz Bandwidth
Video Decoding: MP@ML & MP @ HL
®
Audio Decoding: Dolby Digital, MPEG ( &Ⅱ)
Audio Sampling Rate: 32, 44.1, 48 kHz
Ⅰ
574 (W) x 382 (H) x 100 (D)mm (stand not included)
4.6 kg (stand not included)
