Sanyo LCD-32K40 Service Manual

-18-
White-AVN443 R 00H MST6E16JS
White-AVN443 G 00H MST6E16JS
White-AVN443 B 00H MST6E16JS VIDEO Input→NTSC443
Black-AVN443 R 00H MST6E16JS (Different Value)
Black-AVN443 G 00H MST6E16JS
Black-AVN443 B 00H MST6E16JS
BASEWhite-AVPAL R 75H MST6E16JS
BASEWhite-AVPAL G 75H MST6E16JS
BASEWhite-AVPAL B 75H MST6E16JS VIDEO Input→PAL
BASEBlack-AVPAL R 80H MST6E16JS (BASE)
BASEBlack-AVPAL G 80H MST6E16JS
BASEBlack-AVPAL B 80H MST6E16JS
White-SV(50) -PAL R 00H MST6E16JS
White-SV(50) -PAL G 00H MST6E16JS
White-SV(50) -PAL B 00H MST6E16JS S-Video Input(PAL)
Black-SV(50) -PAL R 00H MST6E16JS (Different Value)
Black-SV(50) -PAL G 00H MST6E16JS
Black-SV(50) -PAL B 00H MST6E16JS
White-S(60) -NTSC R 00H MST6E16JS
White-S(60) -NTSC G 00H MST6E16JS
White-S(60) -NTSC B 00H MST6E16JS S-Video Input(NTSC)
Black-S(60) -NTSC R 00H MST6E16JS (Different Value)
Black-S(60) -NTSC G 00H MST6E16JS
Black-S(60) -NTSC B 00H MST6E16JS
White-RFSECAM R 00H MST6E16JS
White-RFSECAM G 00H MST6E16JS
White-RFSECAM B 00H MST6E16JS TV Input(PAL-M)
Black-RFSECAM R 00H MST6E16JS (Different Value)
Black-RFSECAM G 00H MST6E16JS
Black-RFSECAM B 00H MST6E16JS
White-RFN R 00H MST6E16JS
White-RFN G 00H MST6E16JS
White-RFN B 00H MST6E16JS
Black-RFN R 00H MST6E16JS TV Input(NTSC)
Black-RFN G 00H MST6E16JS (Different Value)
Black-RFN B 00H MST6E16JS
White-RFN443 R 00H MST6E16JS
White-RFN443 G 00H MST6E16JS
White-RFN443 B 00H MST6E16JS
Black-RFN443 R 00H MST6E16JS TV Input(NTSC443)
Black-RFN443 G 00H MST6E16JS (Different Value)
Black-RFN443 B 00H MST6E16JS
White-RFPAL R 00H MST6E16JS
White-RFPAL G 00H MST6E16JS
White-RFPAL B 00H MST6E16JS
Black-RFPAL R 00H MST6E16JS TV Input(PAL)
Black-RFPAL G 00H MST6E16JS (Different Value)
Black-RFPAL B 00H MST6E16JS
EDID YEAR 13H HDMI,VGA EDID YEAR 13h~19h
HST KEYWORD 7AH HST DATA INITIALIZE KEYWORD
Item Name Initial Data IC Description
On-screen Service Menu System
