Sanyo LCD-32K40 Service Manual

-38-
N7TK
T602 6520031036 TRANS,POWER,PULSE
COIL
L1601 6520030992 INDUCTOR,1.0UH
L1603 6520001749 CORE,PIPE
6520029569 CORE,PIPE
L601 6520029170 LINE FILTER
L602 6520029170 LINE FILTER
L603 6520031012 LINE FILTER
L604 6520031586 INDUCTOR ,220UH
L605 6520010130 CORE,PIPE
L616 6520001749 CORE,PIPE
6520029569 CORE,PIPE
DIODE
D1601 4080695705 DIODE STPS10LCD100C
D1606 4080651008 DIODE RS07G
D1607 4070999905 ZENER DIODE MTZJ33B-T-72
D1609 4080695705 DIODE STPS10LCD100C
D1610 4080695606 DIODE STPS10LCD60C
D1611 4072264714 DIODE BAS316,115
D1612 4072091211 ZD UDZS-TE-176.2B
D1613 4072264714 DIODE BAS316,115
D1614 4072312217 ZENER DIODE UDZS13B-TE-17
4080646707 ZENER DIODE MM3Z13B
D1615 4072264714 DIODE BAS316,115
D1616 4072264714 DIODE BAS316,115
D1617 4072219615 ZENER DIODE UDZS27B-TE-17
4080641306 ZENER DIODE MM3Z 27B
D1618 4080651008 DIODE RS07G
D1619 4072264714 DIODE BAS316,115
D603 4080696207 DIODE D4SB80
D604 4072187617 ZENER DIODE UDZS18B-TE-17
D605 4072264714 DIODE BAS316,115
D606 4072537402 DIODE FMXA-1106S
D612 4072264714 DIODE BAS316,115
D613 4072187518 ZENER DIODE UDZS16B-TE-17
4080647506 ZENER DIODE MM3Z 16B
D614 4070997307 ZENER DIODE MTZJ-T-7216B
D615 4072626700 PHOTO COUPLE BPC-817MC
4072348701 PHOTO COUPLE PC123X5YFZ
4072303908 PHOTO COUPLE PC123Y52
4072664801 PHOTO COUPLE PC17L1
D616 4072626700 PHOTO COUPLE BPC-817MC
4072348701 PHOTO COUPLE PC123X5YFZ
4072303908 PHOTO COUPLE PC123Y52
4072664801 PHOTO COUPLE PC17L1
D617 4080584207 DIODE EU1
D618 4080584207 DIODE EU1
D619 4072264714 DIODE BAS316,115
D620 4072219615 ZENER DIODE UDZS27B-TE-17
4080641306 ZENER DIODE MM3Z 27B
D621 4080456603 DIODE EG01C
4080583804 DIODE EG01C
D630 4072264714 DIODE BAS316,115
D631 4072264714 DIODE BAS316,115
D638 4072312217 ZENER DIODE UDZS13B-TE-17
4080646707 ZENER DIODE MM3Z13B
D650 4072626700 PHOTO COUPLE BPC-817MC
4072348701 PHOTO COUPLE PC123X5YFZ
4072303908 PHOTO COUPLE PC123Y52
4072664801 PHOTO COUPLE PC17L1
D652 4072264714 DIODE BAS316,115
MSCELLANEOUS
F602 4240067403 FUSE 250V 5A
VA602 4071712008 VARISTOR ERZV14D471
4080619701 VARISTOR S14K300E2S5M4,2
CABINET PARTS LIST
-- 6103475936 DEC IND RC-N7TW
-- 6103460291 DEC CTRL SHEET-N7TK
-- 6103500560 ASSY,CABINET FRONT-N7TK
-- 6103498751 CABINET FRONT-N7TK
-- 6103405520 BADGE SANYO-N5YV
-- 6103476346 DEC PANEL-N7TW
-- 6103500591 ASSY,CABINET BACK-N7TK
-- 4120673304 SPECIAL SCREW
-- 6103476322 ASSY,CABINET BACK-N7TW
-- 4120755703 SPECIAL NUT
-- 4120789104 SPECIAL NUT
-- 6103476339 CABINET BACK-N7TW
-- 6103475899 SPEAKER HOLDER-N7TW
-- 6103425009 SPACER SPEAKER HOLDER-N6
-- 6520030633 SPEAKER,8
-- 6103500768 ASSY,STAND BASE-N7TK
-- 6103383422 PAD BTM PLATE -N5HA
-- 6103400112 PAD BTM PLATE-N5YV
-- 6103500607 STAND BASE-N7TK
-- 6103475929 LID BACK-N7TW
!
!
!
!
!
!
!
Ref. No. Part No. Description Ref. No. Part No. Description
P List N7TK 2/18/10 7:55 AM Page 38
