6
Main Unit (front view/side view)
Identification of Controls
Functions of CH+/-, VOL+/-, MENU, SOURCE and are also provided to the remote control. This operation manual
provides a description based on operating functions with the remote control.
1. CH+/-
Press these two buttons to directly change the TV channel.
In OSD menu, press these buttons to choose the OSD items.
2. VOL+/-
Press the VOL+ or VOL- button to directly increase or decrease the sound volume level;
In OSD menu, press these buttons to adjust the value or setting of each item.
3. MENU
Press this button to access Menu main page.
4. SOURCE
To access input source select menu.
5. STANDBY SWITCH
Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.
6. POWER SWITCH
Switch this switch ON first before you use the STANDBY switch to power the unit up.
Note
6 Main Power on/off Switch
1
2
4
5
3
SOURCE
MENU
CH+
CH-
VOL+
VOL-
Power Indicator
Remote Sensor
To Next Page
