7） During adjustment, make sure that chromatic coordinates of bright scale are (X=272±10,
Y=278±10) and chromatic coordinates of dark scale are (X=272±10, Y=278±10);
8） Move cursor to item “COPY ALL” again to copy data of white balance to other channels
except DTV;
9） Check if chromatic coordinates of HDMI NORMAL and WARM meet the requirements of
error allowance (dark scale: ±10, bright scale: ±10) or not, otherwise adjust items
“R_GAIN/B_GAIN/R_OFF/B_OFF” to meet them and then save the data;
10) Switch to other channels (ATV, AV，COMPONENT，D-SUB), check if chromatic coordinates
of COOL, NORMAL and WARM meet the requirements or not, if not, adjust them
respectively in the same way of HDMI and with 16 gray scale signal; exit menu “W/B
ADJUST” after adjustment, the data will be save automatically;
11) DTV adjustment: switch to DTV channel, select 16 gray scale program, enter into factory
menu, do adjustment following above step 5, 6, 7;
12) Please refer to the adjusting rules as follows:
B Gun: coordinates of X and Y will increase when B gun is adjusted downwards;
coordinates of X and Y will decrease when B gun is adjusted upwards;
R Gun: adjusting R gun will effect coordinate of X, and value of Lv slightly;
coordinate of X will increase when R gun is adjusted upwards;
coordinate of X will decrease when R gun is adjusted downwards;
G Gun: adjusting G gun will effect coordinate of Y
, and value of Lv greatly;
coordinate of Y will increase when G gun is adjusted upwards;
coordinate of Y will decrease when G gun is adjusted downwards;
Note: Default color temperature specified by SANYO customer is Normal, adjust chromatic
coordinates of Normal and Cool in Dynamic picture mode; adjust chromatic coordinates of Cool in
Dynamic picture mode for other customers.
5 Functions checkup
5.1 TV functions
Input central signal to RF port, enter into menu “CHANNEL” first, then search channels
automatically, check if there is any omitted channel, check if the output of speakers and the picture
are normal.
5.2 AV port
Input signal to AV port respectively, check if the picture and the sound are normal.
5.3 YPbPr/YCbCr port
Input YUV signal from VG848 signal generator with YUV formats listed as Table 3 respectively,
check if the picture and the sound are normal under the circumstances of power-on/off, switching
channel and format, etc..
Table 3 YUV signal formats
No.
Definition
H. - fre.（kHz） V. – fre.（Hz） Dot pulse fre.（MHz）
Note
1 720×480 15.734 60 13.5 480i(NTSC)
2 720×480 15.734 59.94 13.5 480i(NTSC)
3 720×576 15.625 50 13.5 576i(PAL)
4 720×480 31.469 60 27 480p(NTSC PROG)
5 720×480 31.469 59.94 27 480p(NTSC PROG)
