- 1 -
Specifications
㩷
ŶStructural specifications
Item MDF-U500VX / MDF-U500VXC
Name Ultra-Low Temperature Freezer
External dimensions W770 × D870 × H1990 (mm)
Internal dimensions W630 × D600 × H1400 (mm)
Effective capacity 519 L
Exterior Painted steel
Interior Painted steel
Outer door 1, Painted steel
Inner door 2, ABS resin panel with stainless frame
Shelf 3, Stainless steel
Insulation
Rigid polyurethane foamed-in place
+ vacuum insulation panel (VIP PLUS)
Access port 㱢17mm, 3 locations (in upper back, bottom left/right back)
Compressor A circuit; Hermetic type, Output; 1100W
B circuit; Hermetic type, Output; 1100W
Evaporator A circuit; Tube on sheet type
B circuit; Tube on sheet type
Condenser A circuit; Finless tube type
B circuit; Finless tube type
Refrigerant A circuit; MU-N400
B circuit; MU-N400
Refrigerating oil LAB22SA
Power supply Local voltage
Battery Nickel-hydrogen storage battery for power failure alarm,
6VDC, 1100mAh, Auto-recharge
Weight 320 kg / 328 kg
Accessories 1 set of key, 1 scraper
Optional component Temperature recorder (MTR-85H),
Mounting kit for MTR-85H (MDF-S3085)
Back-up kit (CVK-UB2, CVK-UB2(I)):LCO
2
,
Communication IF board (MTR-480),
LAN interface board (MTR-L03), Software (MTR-5000)
9 pin Dsub cross type (RS232C)
