Sanyo MDF-U500VX - Page 42

- 39 -
[
Lower left side / Electric Box
]
Main PCB
[
Lower front / Panel removed
]
AT sensor
[
Rear botton / Coolin
g
unit
]
[
Rear side bottom / coolin
g
unit
]
Condensing fan motor
Compressor A Compressor B
( Terminal cover is removed )
12P terminals
