Error 01~08 (Abnormal in sensor)
LCD indication Symptom/Diagnosis Remedy
Temp. sensor is open circuited Check connections of connectors/lead wires in temp. sensor
Diagnosis: More than 1189ȍ If resistance for temp. sensor is more than 1189ȍ, replace the sensor.
Temp. sensor is short circuited Check connections of connectors/lead wires in temp. sensor
Diagnosis: Less than 450.8ȍ If resistance for temp. sensor is less than 450.8ȍ, replace the sensor.
Comp. sensor A is open circuited Check connections of connectors/lead wires in comp. sensor A.
Diagnosis: More than 154.5ȍ If resistance for comp. sensor A is more than 154.5ȍ, replace the sensor.
Comp. sensor A is short circuited Check connections of connectors/lead wires in comp. sensor A.
Diagnosis: Less than 0.413ȍ If resistance for comp. sensor A is less than 0.413ȍ, replace the sensor.
Comp. sensor B is open circuited Check connections of connectors/lead wires in comp. sensor B.
Diagnosis: More than 154.5ȍ If resistance for comp. sensor B is more than 154.5ȍ, replace the sensor.
Comp. sensor B is short circuited Check connections of connectors/lead wires in comp. sensor B.
Diagnosis: Less than 0.413ȍ If resistance for comp. sensor B is less than 0.413ȍ, replace the sensor.
AT sensor is open circuited Check connections of connectors/lead wires in AT sensor.
Diagnosis: More than 154.5ȍ If resistance for AT sensor is more than 154.5ȍ, replace the sensor.
AT sensor is short circuited Check connections of connectors/lead wires in AT sensor.
Diagnosis: Less than 2.13ȍ If resistance for AT sensor is less than 2.13ȍ, replace the sensor.
Check points:
䇭(1) Check if connector(s) is loosen or disconnected.
scratched.
Error 01 Temperature Sensor is Open
Error 02 Temperature Sensor is Short
Error 03 Condenser Sensor A is Open
Error 04 Condenser Sensor A is Short
Error 05 Condenser Sensor B is Open
Error 06 Condenser Sensor B is Short
Error 07 AT Sensor is Open
Error 08 AT Sensor is Short
