- 6 -
Refrigeration circuit
B circuit
A circuit
Compressor
Frame pipe
Pre-condenser
Pre-condenser
Frame pipe
Compressor
Dryer
Dryer
EX tank
Cap.tube (EX)
Shunt
Cap.tube
Cap.tube
Evaporator
Cap.tube
Evaporator
Cap.tube (EX)
Shunt
Condenser
Condenser
EX tank
Cap.tube
Cascade condenser
Cascade condenser
