SPECIFICATIONS
Name Ultra-Low Temperature Freezer
Model MDF-U7386S MDF-U7386SC (for U.S.A. only)
External dimensions W1130 x D867 x H1990 (mm)
Internal dimensions W870 x D600 x H1280 (mm)
Effective capacity 668 L
Exterior Painted steel
Interior Painted steel
Outer door Painted steel
Inner door ABS resin panel with stainless frame, 2 doors
Shelf Stainless steel, 3 shelves (adjustable)
W848 x D533 (mm), Load; 50 kg/shelf
Access port 17 mm diameter, 3 locations (back, bottom left/right corner)
Insulation Rigid polyurethane foamed-in place
Compressor Hermetic type, Output; 1100 W (high stage side), 1100W (low stage side)
Evaporator Tube on sheet type
Condenser Fin and tube type (high stage side), Shell and tube type (low stage side)
Refrigerant R-407D (high stage side), R-508 (low stage side)
Temperature controller Microcomputer control system
Temperature display Digital display
Thermal sensor
Platinum resistance (Pt 1000㱅)
Alarm High temp. alarm, Low temp. alarm, Power failure alarm
Filter check, Battery alarm
Remote alarm contact Allowable contact capacity: DC 30V, 2A
Battery Nickel-metal-hydride battery, DC6V, 1100mAh, Auto-recharge
Accessories 1 set of key, 1 scraper
Weight 355 kg 360 kg
Voltage booster None Built-in
Optional component Inventory rack (IR-220U)
Automatic temperature recorder (MTR-G85)
Back-up system (CVK-UB2): LCO
2
Note:
• Design or specifications will be subject to change without notice.
• The battery for power failure alarm is an article for consumption. It is recommended that the battery will be
replaced about every 3 years. Contact Sanyo sales agency at the time of replacement of the battery for recycling.
PERFORMANCE
Cooling performance -86
o
C at the center of the chamber (ambient temperature; 30
o
C, no load)
Temperature control range -50
o
C to -86
o
C (ambient temperature; 30
o
C, no load)
Power source 220V, 50Hz 220V, 60Hz 230V, 50Hz 240V, 50Hz
Rated power consumption 1080 W 1210 W 1140 W 1120 W
Noise level 49 dB [A] (background noise; 20 dB)
Maximum pressure 2.7 MPa
Note : The unit with CE mark complies with EC directives 89/336/EEC, 93/68/EEC and 73/23/EEC
