20
Change to the desired value in the range “-4.9”~”04.9” with key
and key.
Press SET key to store the value and revert to PV display.
F08: <Purpose> To calibrate temperature of cascade sensor
<Operation> Input service code in F06 prior to use this mode.
Input F08 and press SET key to display “00.0” (initial value).
Change to the desire value in the range “-9.9”~”09.9” with key
and key.
Press SET key to store the value and revert to PV display.
F12:
<Purpose>
To display t
he temperature
of temp. sens
or
<Operation> Input service code in F06 prior to use this mode.
Input F12 and press SET key to display alternately F12 and “XX.X”
(present internal temperature). Press SET key to revert to PV
display. 3 digits indication. Minus “-“ is not indicated.
Ex) “-85.5㷄” 㸢㩷 indicated as “85.5”
F13:
<Purpose>
To display t
he temperature
of cascade sensor
<Operation> Input service code in F06 prior to use this mode.
Input F13 and press SET key to display alternately F13 and “XX.X”
(present temperature of cascade sensor). Press SET key to revert to
PV display.
F14:
<Purpose>
To display the temperature of filter se
nsor
<Operation> Input service code in F06 prior to use this mode.
Input F14 and press SET key to display alternately F14 and “XX.X”
(present temperature of filter sensor). Press SET key to revert to PV
display.
F15:
<Purpose>
To display t
he temperature
of AT sensor
<Operation> Input service code in F06 prior to use this mode.
Input F15 and press SET key to display alternately F15 and “XX.X”
(present temperature of AT sensor). Press SET key to revert to PV
display.
F16: <Purpose> Simply passing through if entered by mistake.
<Operation> Press SET key in “F16” displayed to revert to PV display.
F17: <Purpose> Non-volatile memory initialization, model code change
<Operation> Service code should be input in F06 prior to use this mode.
Input F17 and press SET key to display “001”. Change the value
with key and key. Press SET key to store and revert to PV
display.
Model code ‘007’: MDF-U53V/U53VC
F18: <Purpose> To turn capillary heater forcibly on (or off)
<Operation> Service code should be input in F06 prior to use this mode.
Input F18 and Press SET key to display “000” (initial).
Change to desire value “000” or “001” with key and key.
Press SET key to store the value and revert to PV display.
000: Capillary heater is turned on to off, or turned off to on
001: Capillary heater is forcibly turned off
F21:
<Purpose>
Serial c
ommunicati
on ID setting
<Operation> Input F21 and press SET key to display “000” (initial).
Change the value in the range “001”~”255” with key and key.
F22:
<Purpose>
Serial c
ommunication m
ode setting
<Operation> input F22 and press SET key to display “000” (initial value)
Change the value with key and key.
