Impressive brightness and contrast ratio
A 260-W 2-lamp system combined with a high-contrast optical system featuring
DynamicBlack™ technology deliver an impressive 4,500 lumens of brightness
and a contrast of 2,100:1.
True WIDE-XGA resolution (1280 x 768)
Compatible with wide screen laptop for a true wide screen WXGA(15:9)
DLP
®
projector with high resolution
The combination of BrilliantColor™ and a six-segment color wheel (optional) offer
more true color reproduction.
Network control / administration
SANYO’s standard RJ45 LAN feature allows for control and administration of a
projector via a network. Projector status can be monitored and projector
functions can be controlled through a web browser. A notification can be
automatically sent via e-mail whenever the projector encounters a problem,
allowing the administrator to act quickly to resolve any issues.
By replacing the lens, the user can choose any projection range from 5.9’ to 61.0’
when projecting onto a 100-inch screen. As a result, a wide variety of installation
options are available.
Optional lenses
Five Optional Lens Types
Helpful maintenance functions
The lamp and filter maintenance functions provide for better and proper
maintenance of the projector. An easy maintenance cover is provided for lamp and
color wheel replacement.
Easy power off and on start
The Easy Power Off function allows the projector to be turned off (even when
projecting an image) using a power strip equipped with a switch and a breaker.
The On Start function allows the projector to be turned on by supplied AC power.
Dual lamp control system
The two-lamp control system offers high brightness, long lamp life and energy
savings along with a secure redundant system. The lamp control function allows
the brightness of the lamp to be selected. The power management function also
reduces power consumption and maintains long lamp life.
One-touch lens exchange system
Attaching the included easy lens attachment to your lenses makes installation and
removal of our optional lenses quick and easy with a one- touch release button.
LNS-W41
Fixed/Power
0.77:1
2.0
2.2 lbs.
LNS-W40
x1.34/Power
1.33-1.79:1
1.8-2.3
2.4 lbs.
LNS-S40
x1.32/Power
1.78-2.35:1
1.7-1.9
1.8 lbs.
LNS-T40
x2.0/Power
2.22-4.43:1
2.1-2.9
2.6 lbs.
LNS-T41
x1.85/Power
4.43-8.3:1
2.2-3.1
2.0 lbs.
Model
Zoom/Focus
Throw Ratio
F Stop
Weight
On Axis
Short Fixed
Short
Zoom
Standard
Zoom
Long
Zoom
Ultra Long
Zoom
Specifications
PDG-DWT50L
Model name
Resolution
Brightness (typical)
Uniformity
DMD Panel System
Number of Pixels
Contrast Ratio
Projection Image (diagonal)
Aspect Ratio
Power Lens Shift
Digital Keystone Correction
Projection Lens
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
Sound Output
Voltage
BTU Rating
Fan noise
Power Consumption
Dimensions (W x H x D)
Net Weight
User Maintenance
Input Terminal Computer 1
Input Terminal Computer 2
Input Terminal Computer 3
Input Terminal Component
Input Terminal Video, S-Video
Output Terminals
Because its products are subject to continuous improvement, SANYO reserves the right to modify product design
and specifications without notice and without incurring any obligations.
Optional Accessories
Included Accessories
Additional Input Terminals
·
Wired remote control jack x 1 (stereo mini jack)
·
USB type B x 1
·
RS232C Control Port x 1 (D-sub9pin)
·
RJ45 LAN
·
Remote control 15pin GPIO
· Wired/Wireless Remote Control · Batteries (two “AA”)
· AC power cord · Wired remote cable · Lens holeprotection
· Owner’s manual(CD-ROM & Quick Reference Guide)
· Computer cable · Anti theft screw for lens · PIN code lock label
· Replacement Lamp (610 335 8406)
· Optional Lenses (see below)
· Optional 6 segment Color Wheel (RGBCMY)
· POA-CA-RC30 (Remote control wired cable 30m)
External dimensions
WXGA (1280 x 768)
4500 Lumens
85 % (Center to corner)
0.65”WXGA-LVDS DMD x 1
983,040
2100:1 (with DynamicBlack™ )
40”-500” (Dependent on Lens)
15:9
Up/ Down 0 – + 77 % Left/ Right ± 10 %
Vert. + / - 40∞ MAX, Horiz. + / - 35∞ MAX
Lens Sold Separately
260 W x 2
H 15 kHz, 31-90 kHz; V 50-85 Hz
170 MHz
PAL/ PAL-M/ PAL-N/ SECAM/ NTSC/ NTSC4.43
UXGA/ SXGA+/ SXGA/ WXGA/ XGA / SVGA/ VGA / MAC/ HDT
3 W stereo
100-240 V AC; Auto voltage
2354
34 dBA (Eco & Dual lamp mode)
690 W
19.9 x 8.0 x 15.2 inch
36.3 lbs.
Clean air filters, replace lamp assembly
·
D-Sub 15 x 1
·
Audio x 1 (stereo mini jack)
·
RGBHV or Y/ Cb/ Cr (BNC x 5)
·
Audio x1 (stereo mini jack)
·
DVI-D x1 (HDCP)
·
Audio x1 (stereo mini jack)
·
Component Video (RCA x 3)
·
L & R Audio (RCA x 2)
·
Composite Video (RCA x 1)
·
S-Video x 1
·
L & R Audio (RCA x 2)
· D-Sub 15 x 1 · Audio x 1 (stereo mini-jack)
SANYO Presentation Technologies
© 2009 SANYO Presentation Technologies.
Caution: Please consult the instruction manual to ensure safe and proper operation of the product.
Toll free:
888-337-1215 www.sanyoprojectors.com
