Sanyo PLC-XW57

65
Appendix
Terminal: Mini DIN 8-PIN
SERVICE PORT CONNECTOR
COMPUTER IN/S-VIDEO IN/COMPONENT IN/MONITOR OUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
Red (R/Cr/S-C) Input/R Output
Ground (Horiz.sync.)
Green (G/Y/S-Y) Input/G Output
-----
Blue (B/Cb/---) Input/B Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
5V / ---
Horiz. sync. Input/Output ，Composite H/V sync.Input
Ground (Vert.sync.)
DDC data / ---
Ground
Vert. sync. Input/Output
DDC clock / ---
9
13
10
12
11
14
15
Serial
GND
R X D
-----
-----
-----
T X D
-----
4
1
3
2
5
6
7
-----8
