(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
Control wiring
(C) Inter-unit (between outdoor and
indoor units) control wiring
(D) Remote control wiring (E) Control wiring for group control
(F) Inter-outdoor unit control wiring
0.75 mm
2
(AWG #18)
0.75 mm
2
(AWG #18)
0.75 mm
2
(AWG #18)
Use shielded wiring* Use shielded wiring Use shielded wiring
0.75 mm
2
(AWG #18)
Use shielded wiring
Max. 200 m (Total)
Outdoor unit
(A) Power supply
(A) Power supply
Wire size Max. length
Wire size Max. length
SPW-C0705DZH8
SPW-C0905DZH8
SPW-C1155DZH8
SPW-C1305DZH8
SPW-C1405DZH8
6 mm
6 mm
6 mm
10 mm
10 mm
6 mm
2
6 mm
2
10 mm
2
10 mm
2
10 mm
2
2
2
2
2
2
Time delay fuse or
circuit capacity
Time delay fuse or
circuit capacity
or
NOTE
3-1. General Precautions on Wiring
Before wiring, confirm the rated voltage of the unit
as shown on its nameplate, then carry out the
wiring closely following the wiring diagram.
Provide a power outlet to be used exclusively for
each unit, and a power supply disconnect and cir-
cuit breaker for overcurrent protection should be
provided in the exclusive line.
To prevent possible hazards from insulation failure,
the unit must be grounded.
Each wiring connection must be done in accor-
dance with the wiring system diagram. Wrong
wiring may cause the unit to misoperate or
become damaged.
Do not allow wiring to touch the refrigerant tubing,
compressor, or any moving parts of the fan.
Unauthorized changes in the internal wiring can be
very dangerous. The manufacturer will accept no
responsibility for any damage or misoperation that
occurs as a result of such unauthorized changes.
Regulations on wire diameters differ from locality to
locality. For field wiring rules, please refer to your
LOCAL ELECTRICAL CODES before beginning.
You must ensure that installation complies with all
relevant rules and regulations.
To prevent malfunction of the air conditioner
caused by electrical noise, care must be taken
when wiring as follows:
The remote control wiring and the inter-unit control
wiring should be wired apart from the inter-unit
power wiring.
If the power supply cord of this appliance is dam-
aged, it must be replaced by a repair shop
appointed by the manufacture, because special
purpose tools are required.
Use shielded wires for inter-unit control wiring
between units and ground the shield on both sides.
3-2. Recommended Wire Length and Wire Diameter for Power Supply System
* With ring-type wire terminal.
30 A
35 A
40 A
40 A
50 A
92 m
70 m
57 m
79 m
68 m
92 m
70 m
95 m
79 m
68 m
35 A
35 A
50 A
50 A
50 A
Max. 1,000 m
Max. 500 m
Max. 300 m
2-24
Design of 3-WAY ECO-i SYSTEM
1
2
3
4
5
6
7
8
3. Electrical Wiring
Indoor unit
Type
(B) Power supply
Time delay fuse or
circuit capacity
2.5 mm²
K Max. 150 m 10 – 16A
A, L, S, X, XM, T, U, US, F, FM
Max. 130 m 10 – 16A
D (254, 364, 484) Max. 60 m 10 – 16A
D (764) Max. 50 m 10 – 16A
D (964) Max. 30 m 10 – 16A
GU055XH Max. 85 m 10 – 16A
GU075XH Max. 65 m 10 – 16A
GU105XH Max. 60 m 10 – 16A
TD831143-00W-3WAY.indb24TD831143-00W-3WAY.indb24 2008/12/0116:15:452008/12/0116:15:45
