Sanyo SPW-CR483GVH8 User Manual

III - 27
SM830063
3
1. Troubleshooting
Service Procedures
1. Troubleshooting
This picture shows the service check display.
For example, if the last four alarm messages were, in order of occurrence from oldest to most recent, P01, P02, P04,
and most recently E01, then the display will be shown as below when you press
button four times. The 5th time you
press
button you can repeat the display, then the first message will be shown again.
c. A maximum of 4 alarm messages can be accessed by pressing either SET TEMP button
or as follows.
NOTE Pressing CL (Clear) button will clear all
the service history.
... accessed in order of “Past È Present”.
... accessed in order of “Present È Past”.
SERVICE
R.C. No.
CHECK
UNIT No.
No.CODE
0358_M_I
CODE No.
No.
UNIT No.
1–1
Alarm message
Refrigerant
Circuit No.
0359_M_I
Present
Past
Present
Past
MODE
FAN SPEED
SET TEMP.
0360_M_I
SERVICE
R.C. No.
CHECK
UNIT No.
No.CODE
SERVICE
R.C. No.
CHECK
UNIT No.
No.CODE
SERVICE
R.C. No.
CHECK
UNIT No.
No.CODE
SERVICE
R.C. No.
CHECK
UNIT No.
No.CODE
SERVICE
R.C. No.
CHECK
UNIT No.
No.CODE
If there are no alarm messages, the display shows:
Alarm message
1234

Sanyo SPW-CR483GVH8 Specifications

General

Cooling Capacity	48000 BTU/h
Refrigerant	R410A
Coefficient of Performance (COP)	3.2
Type	Split System
Noise Level (Outdoor Unit)	58 dB
