4. PARTS LIST (R)
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ACCESSORIES & PACKING MATERIALS
9110 613 212 1934 INST MANUAL,MAIN A4,English,
VCC-MC800P ONLY
9110 613 212 3716 INST MANUAL,MAIN LT,English,
VCC-MC800 ONLY
9111 613 212 1941 INST MANUAL,SETUP A4,
English,French,German,Chinese
9119 645 092 0059 DISC,MANUAL,English,French,
Spanish,German,Chinese,VCC-MC800P ONLY
9119 645 092 2855 DISC,MANUAL,English,French,Spanish
VCC-MC800 ONLY
9201 613 203 0465 BAG POLY AIR-0150X0120*NC
9205 645 052 1980 CORE,FERRITE
9206 645 052 1997 CORE,FERRITE
7001 613 211 3908 CARTON CASE INNER
7002 645 009 3432 POLY SHEET-0600X0300*NC
7003 613 211 7357 CUSHION SHEET
7004 613 211 3960 REINFORCEMENT,PAD-A
7005 613 211 3977 REINFORCEMENT,PAD-B
7006 613 211 7340 CUSHION,TOP
7101 613 139 4902 POLYETHYLENE,VCC-MC800P ONLY
7101 613 062 8664 POLYETHYLENE COVER,VCC-MC800 ONLY
CABINET & CHASSIS PARTS 1
5001 613 210 9833 DEC COVER
5002 613 210 9840 CABINET MAIN
5003 613 210 9857 LEVER LOCK
5004 613 210 9864 SPRING LEVER
5005 613 211 4615 COVER DUST
5006 613 212 5079 SPACER-L5BU2/XE
5007 613 211 3663 SPACER LEVER
5008 613 211 3656 MOUNTING SAFETY WIRE
5009 613 211 3649 COVER SAFETY WIRE
5010 613 211 7692 SPACER FAN
5014 613 211 0556 SPACER SHEET
5016 613 211 6930 LABEL ARROW-RED
5017 613 211 6954 LABEL ARROW-BLUE
5018 613 212 3549 PIPE,FAN
5019 645 041 0314 FIXER,14.2X19.6
5021 613 212 4409 SPACER DOME
TB-1 613 210 9048 COMPL PWB,TB-1
M2001 645 091 5192 MOTOR,FAN DC 0.55W
NJ510 411 191 9107 SCR BIN 3X8
NJ520 411 214 8902 SCR PAN+W 2X4
NJ530 411 197 3307 SCR BIN 2X12
NJ531 411 203 9309 WASHER V 2X6X0.4
NJ540 411 030 5406 SCR BIN 2X4
NJ550 411 087 7705 WASHER V 3X8X0.5
NJ560 613 201 0016 PIPE
NJ570 411 030 7004 SCR BIN 2X6
NJ580 411 030 5406 SCR BIN 2X4
NJ595 411 031 8604 SCR BIN 3X6
