18
ELECTRICAL PARTS
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
POS-SOLID Polymerized Organic Semiconductor Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U : µF P : pF
4. Inductors
UH : µH MH : mH
5. N.S.P. : Not available as service parts.
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
COMPL PWB,CA-1
613 210 6290
(SEMICONDUCTOR)
Q1102 305 153 6702 TR 2SC3931-D
(INTEGRATED CIRCUITS)
IC102 309 446 8701 IC CXD3400N
IC103 310 607 4302 IC AD9948AKCPZW
IC104 645 088 3149 GYRO SENSOR
IC105 309 534 2703 IC XC6201P332M
IC106 309 534 2703 IC XC6201P332M
(DIODE)
D1101 307 210 1903 DIODE 1SS400
(INDUCTOR)
L1301 945 066 4725 IMPEDANCE,600 OHM P
(CAPACITORS)
CB101 303 392 5500 CERAMIC 1U K 6.3V
C1102 303 338 0309 CERAMIC 0.1U K 10V
C1103 303 338 0309 CERAMIC 0.1U K 10V
C1106 303 342 3303 CERAMIC 0.1U K 25V
C1108 303 420 7209 CERAMIC 10U K 10V
C1109 303 338 0309 CERAMIC 0.1U K 10V
C1110 303 420 7902 CERAMIC 10U K 16V
C1111 303 420 7902 CERAMIC 10U K 16V
C1112 303 397 7608 CERAMIC 1U K 25V
C1113 303 342 3303 CERAMIC 0.1U K 25V
C1114 303 420 7902 CERAMIC 10U K 16V
C1115 303 155 1800 CERAMIC 0.01U K 25V
C1116 303 283 5701 CERAMIC 2200P K 50V
C1117 303 155 1800 CERAMIC 0.01U K 25V
C1118 303 420 7902 CERAMIC 10U K 16V
C1121 303 420 7209 CERAMIC 10U K 10V
C1122 303 420 7902 CERAMIC 10U K 16V
C1123 303 420 7902 CERAMIC 10U K 16V
C1135 303 323 6309 CERAMIC 0.1U K 16V
C1137 303 342 3303 CERAMIC 0.1U K 25V
C1138 303 323 6309 CERAMIC 0.1U K 16V
C1139 303 323 6309 CERAMIC 0.1U K 16V
C1301 303 338 0309 CERAMIC 0.1U K 10V
C1302 303 384 6508 CERAMIC 10U K 6.3V
C1304 303 384 6508 CERAMIC 10U K 6.3V
C1305 303 338 0309 CERAMIC 0.1U K 10V
C1307 303 338 0309 CERAMIC 0.1U K 10V
C1308 303 384 6508 CERAMIC 10U K 6.3V
C1309 303 338 0309 CERAMIC 0.1U K 10V
C1310 303 312 6808 CERAMIC 0.1U Z 16V
C1314 303 338 0309 CERAMIC 0.1U K 10V
C1316 303 384 6508 CERAMIC 10U K 6.3V
C1319 303 338 0309 CERAMIC 0.1U K 10V
C1321 303 378 5302 CERAMIC 1U K 10V
C1323 303 378 5302 CERAMIC 1U K 10V
C1324 303 381 8109 CERAMIC 1U K 6.3V
C1401 304 107 6300 CERAMIC 4.7U K 16V
C1402 303 326 2704 CERAMIC 0.015U K 16V
C1403 303 274 4102 CERAMIC 1500P K 50V
C1406 303 274 4102 CERAMIC 1500P K 50V
C1407 304 107 6300 CERAMIC 4.7U K 16V
C1408 303 326 2704 CERAMIC 0.015U K 16V
C1409 303 338 0309 CERAMIC 0.1U K 10V
C1411 303 387 3009 CERAMIC 4.7U K 10V
C1414 303 383 5205 CERAMIC 4.7U K 6.3V
C1417 303 380 6601 CERAMIC 0.22U K 6.3V
C1418 303 380 6601 CERAMIC 0.22U K 6.3V
(RESISTOR PACKS)
RB101 945 049 0690 R-NETWORK 33X4 1/16W
RB102 945 049 0690 R-NETWORK 33X4 1/16W
RB103 945 049 0690 R-NETWORK 33X4 1/16W
(RESISTORS)
R1101 301 225 0906 MT-GLAZE 82K JA 1/16W
R1102 301 224 8903 MT-GLAZE 100K JA 1/16W
R1103 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1104 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1105 301 235 1405 MT-GALZE 1.2K JA 1/16W
R1106 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R1109 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1141 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1304 301 225 8100 MT-GLAZE 10 JA 1/16W
R1305 301 225 8100 MT-GLAZE 10 JA 1/16W
R1306 301 225 8100 MT-GLAZE 10 JA 1/16W
R1307 301 148 6009 MT-GLAZE 2.2 JA 1/16W
R1311 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1401 301 225 9008 MT-GLAZE 470K JA 1/16W
R1402 301 225 2108 MT-GLAZE 12K JA 1/16W
R1403 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1404 301 225 2108 MT-GLAZE 12K JA 1/16W
R1405 301 225 9008 MT-GLAZE 470K JA 1/16W
R1411 301 148 6009 MT-GLAZE 2.2 JA 1/16W
(CONNECTORS)
CN102 645 075 5378 PLUG,PWB-PWB 50P (N.S.P)
COMPL PWB,CA-2 F/W
613 211 3052 VCC-MC800P ONLY
613 211 3069 VCC-MC800 ONLY
(SEMICONDUCTORS)
Q2001 305 167 0307 TR EMD3
Q2004 305 167 0307 TR EMD3,VCC-MC800P ONLY
Q2101 305 168 4502 TR 2SA2029-R
Q2102 305 172 8800 TR 2SC5658-R
To Next Page
