LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
Q2103 305 168 4502 TR 2SA2029-R
Q2104 305 172 8800 TR 2SC5658-R
Q2450 305 165 1108 TR EMH11
(INTEGRATED CIRCUITS)
IC201 310 558 7001 IC SCC0030A A
IC202 309 320 9107 IC TC7SU04FU
IC203 309 323 9005 IC TC7S04FU
IC205 309 320 9107 IC TC7SU04FU,VCC-MC800P ONLY
IC206 309 323 9005 IC TC7S04FU,VCC-MC800P ONLY
IC208 409 678 8309 IC UPC358GR-9LG-A
IC214 309 478 2203 IC NJM2274R
IC231 410 623 2808 IC UPD70F3716GC-8EA-A (N.S.P)
IC232 410 626 3901 IC AT24C128-10TU-2.7
IC233 309 541 4806 IC BD4829G
IC234 410 635 0106 IC UPD6467GR-580-A
OR 410 635 0205 IC UPD6467GR-001-A
IC236 309 673 7300 IC W9816G6CH-7
IC251 309 320 9107 IC TC7SU04FU
IC252 309 323 9005 IC TC7S04FU
IC261 309 610 7707 IC UPD168117K9-9B4-A
IC262 309 646 8709 IC AK7331
IC273 309 400 9102 IC TC7SET08FU
IC274 309 330 2501 IC TC7SH04FU
(DIODES)
D2001 307 215 9201 DIODE MA365(E)
D2002 307 215 9201 DIODE MA365(E),VCC-MC800P ONLY
D2140 307 210 1903 DIODE 1SS400
D2751 307 248 2408 ZENER DIODE EDZ7.5B
D2752 307 248 2408 ZENER DIODE EDZ7.5B
D2753 307 248 2408 ZENER DIODE EDZ7.5B
D2754 307 248 2408 ZENER DIODE EDZ7.5B
D2755 307 248 2408 ZENER DIODE EDZ7.5B
D2756 307 248 2408 ZENER DIODE EDZ7.5B
D2757 307 248 2408 ZENER DIODE EDZ7.5B
D2758 307 248 2408 ZENER DIODE EDZ7.5B
D2759 307 229 6807 DIODE RSX101M-30
(OSCILLATORS)
X2001 645 055 5299 OSC,CRYSTAL 14.1875MHZ,VCC-MC800P ONLY
X2140 945 053 3878 OSC,CERAMIC 5.00MHZ
X2501 645 049 0590 OSC,CRYSTAL 14.31818MHZ,VCC-MC800 ONLY
X2501 645 055 5282 OSC,CRYSTAL 17.734475MHZ,
VCC-MC800P ONLY
(TRIMMERS)
CT201 645 069 5131 TRIMMER,30PF
CT202 645 069 5131 TRIMMER,30PF,VCC-MC800P ONLY
CT252 645 069 5131 TRIMMER,30PF
(INDUCTORS)
L2001 945 043 5882 INDUCTOR,10U J
L2002 945 007 6863 INDUCTOR,5.6U J
L2003 945 043 5899 INDUCTOR,47U J
L2040 945 043 5882 INDUCTOR,10U J
L2101 945 043 5882 INDUCTOR,10U J
L2121 945 055 3135 INDUCTOR,68U J
L2131 945 043 7381 INDUCTOR,33U J
L2141 945 043 5882 INDUCTOR,10U J
L2142 945 043 5882 INDUCTOR,10U J
L2301 945 043 5882 INDUCTOR,10U J
L2302 945 043 5882 INDUCTOR,10U J
L2303 945 043 5882 INDUCTOR,10U J
L2304 945 043 5882 INDUCTOR,10U J
L2305 945 043 5882 INDUCTOR,10U J
L2306 945 043 5882 INDUCTOR,10U J
L2603 645 018 3553 INDUCTOR,1000 OHM
L2604 645 018 3553 INDUCTOR,1000 OHM
L2605 645 018 3553 INDUCTOR,1000 OHM
L2606 645 018 3553 INDUCTOR,1000 OHM
(CAPACITORS)
C2001 303 418 0007 CERAMIC 4.7U K 25V
C2002 303 397 7608 CERAMIC 1U K 25V
C2004 303 164 0207 CERAMIC 0.1U Z 25V
C2006 303 276 1000 CERAMIC 0.01U K 16V,
VCC-MC800P ONLY
C2007 303 276 1000 CERAMIC 0.01U K 16V,
VCC-MC800P ONLY
C2008 303 338 0309 CERAMIC 0.1U K 10V,VCC-MC800P ONLY
C2011 303 420 7209 CERAMIC 10U K 10V
C2012 303 338 0309 CERAMIC 0.1U K 10V
C2013 303 338 0309 CERAMIC 0.1U K 10V
C2014 303 276 1000 CERAMIC 0.01U K 16V
C2015 303 276 1901 CERAMIC 22P J 50V
C2016 303 276 1307 CERAMIC 1000P K 50V
C2018 303 418 0007 CERAMIC 4.7U K 25V
C2019 303 420 7209 CERAMIC 10U K 10V
C2020 303 338 0309 CERAMIC 0.1U K 10V,VCC-MC800P ONLY
C2021 303 420 7209 CERAMIC 10U K 10V,VCC-MC800P ONLY
C2022 303 276 1307 CERAMIC 1000P K 50V,
VCC-MC800P ONLY
C2023 303 276 1307 CERAMIC 1000P K 50V,
VCC-MC800P ONLY
C2026 303 420 7209 CERAMIC 10U K 10V
C2027 303 338 0309 CERAMIC 0.1U K 10V
C2028 303 338 0309 CERAMIC 0.1U K 10V
C2030 303 309 8204 CERAMIC 6P D 50V
C2031 303 418 0007 CERAMIC 4.7U K 25V
C2033 303 418 0007 CERAMIC 4.7U K 25V,VCC-MC800P ONLY
C2040 303 420 7209 CERAMIC 10U K 10V
C2080 303 338 0309 CERAMIC 0.1U K 10V
C2109 303 378 3605 POS-SOLID 33U M 10V
C2111 303 276 2809 CERAMIC 18P J 50V,VCC-MC800P ONLY
C2111 303 309 2509 CERAMIC 27P J 50V,VCC-MC800 ONLY
C2115 303 349 1401 CERAMIC 0.01U K 25V
C2123 303 338 0309 CERAMIC 0.1U K 10V
C2132 303 305 8505 CERAMIC 15P J 50V
C2133 303 305 8505 CERAMIC 15P J 50V
C2140 303 338 0309 CERAMIC 0.1U K 10V
C2142 303 338 0309 CERAMIC 0.1U K 10V
C2143 303 338 0309 CERAMIC 0.1U K 10V
C2144 303 393 2607 CERAMIC 22U M 6.3V
C2145 303 381 4804 ELECT 100U M 6.3V
C2146 303 378 5302 CERAMIC 1U K 10V
C2149 303 338 0309 CERAMIC 0.1U K 10V
C2150 303 420 7209 CERAMIC 10U K 10V
C2151 303 338 0309 CERAMIC 0.1U K 10V
C2160 303 393 2607 CERAMIC 22U M 6.3V
C2161 303 338 0309 CERAMIC 0.1U K 10V
C2162 303 338 0309 CERAMIC 0.1U K 10V
C2163 303 387 3009 CERAMIC 4.7U K 10V
C2164 303 338 0309 CERAMIC 0.1U K 10V
C2165 303 338 0309 CERAMIC 0.1U K 10V
C2166 303 420 7209 CERAMIC 10U K 10V
C2301 303 420 7209 CERAMIC 10U K 10V
C2302 303 338 0309 CERAMIC 0.1U K 10V
C2303 303 338 0309 CERAMIC 0.1U K 10V
C2304 303 338 0309 CERAMIC 0.1U K 10V
C2305 303 338 0309 CERAMIC 0.1U K 10V
C2306 303 338 0309 CERAMIC 0.1U K 10V
C2307 303 338 0309 CERAMIC 0.1U K 10V
C2308 303 338 0309 CERAMIC 0.1U K 10V
C2309 303 338 0309 CERAMIC 0.1U K 10V
C2310 303 338 0309 CERAMIC 0.1U K 10V
C2311 303 420 7209 CERAMIC 10U K 10V
C2312 303 338 0309 CERAMIC 0.1U K 10V
C2313 303 420 7209 CERAMIC 10U K 10V
C2314 303 338 0309 CERAMIC 0.1U K 10V
C2315 303 338 0309 CERAMIC 0.1U K 10V
C2316 303 338 0309 CERAMIC 0.1U K 10V
C2317 303 338 0309 CERAMIC 0.1U K 10V
C2318 303 420 7209 CERAMIC 10U K 10V
C2319 303 338 0309 CERAMIC 0.1U K 10V
C2320 303 393 2607 CERAMIC 22U M 6.3V
C2321 303 393 2607 CERAMIC 22U M 6.3V
C2322 303 338 0309 CERAMIC 0.1U K 10V
C2324 303 338 0309 CERAMIC 0.1U K 10V
C2325 303 338 0309 CERAMIC 0.1U K 10V
C2330 303 420 7209 CERAMIC 10U K 10V
C2331 303 338 0309 CERAMIC 0.1U K 10V
C2333 303 338 0309 CERAMIC 0.1U K 10V
C2450 303 338 0309 CERAMIC 0.1U K 10V
C2501 303 338 0309 CERAMIC 0.1U K 10V
C2502 303 276 1901 CERAMIC 22P J 50V,VCC-MC800P ONLY
C2502 303 276 2908 CERAMIC 12P J 50V,VCC-MC800 ONLY
C2601 303 382 7804 CERAMIC 2.2U K 10V
C2603 303 276 1307 CERAMIC 1000P K 50V
C2604 303 276 1307 CERAMIC 1000P K 50V
